CNC boring and milling machine of CTX5235 in stock for sale
CNC boring and milling machine of CTX5235 in stock for sale
Specifications
Place of Origin :
China
Brand Name :
Shengyong
Model Number :
CNC boring and milling machine
Certification :
iso
Description

Hengshui Shengyong Heavy-duty Machine Tool Manufacturing Co.,Ltdspecializes in the researches, developments, manufactures and sells of metalworking machines: turning cutting lathe,vertical Turning Lathe, vertical turret lathe，cnc turret lathe ,cnc lathe machine,Singlecolumn vertical lathe , Double columnvertical lathe machine ,Heavy duty horizontal lathe machine,Gantry milling machine,boring milling machine etc.

CNC boring and milling machine of CTX5235

Number

Title

1

Table diameter

2830/ 3150mm

2

Max.turning diameter of workpiece

3500mm

3

Max. Height of workpiece

1600/2000/2200/2500/3000mm

4

Max. Weight of workpiece

10/20T

5

Max cutting force of carriage,right tool post

35000N

6

Max.torque of table

63000N·m

7

Step of table speed

16 step

8

speed range of table

2~63rpm

9

Step of feed rate

No data

10

Feed range

1~2000mm/min

11

Horizontal travel of tool post

1750mm

12

Vertical travel of tool post

1000mm

13

Rapid traverse speed of crossrail

350mm/min

14

Rapid traverse speed of tool post

2000mm/min

15

Max.Rotation range of tool post

±30°

16

Travel of Left boring and milling head

600mm

17

Step of Left boring and milling head

8 Step

18

Speed change of Left boring and milling head

66-660r/min

19

Max.turning diameter of boring hole of Left boring and milling head

Ø400mm

20

Size of toolholder clamping((W×H)

40×50mm

21

Power of main motor

55KW

22

Machine weight(appr)

38T
