High precision heavy duty metal lathes machine price for sale
High precision heavy duty metal lathes machine price for sale
Specifications
Place of Origin :
China
Brand Name :
Shengyong
Model Number :
heavy duty metal lathe
Certification :
iso
Description

Hengshui Shengyong Heavy-duty Machine Tool Manufacturing Co.,Ltdspecializes in the researches, developments, manufactures and sells of metalworking machines: turning cutting lathe,vertical Turning Lathe, vertical turret lathe，cnc turret lathe ,cnc lathe machine,Singlecolumn vertical lathe , Double columnvertical lathe machine ,Heavy duty horizontal lathe machine,Gantry milling machine,boring milling machine etc.

NO

UNIT

heavy duty metal lathes

C5120A

1

Table diameter

mm

1800

2

Max.turning diameter

mm

2000

3

Max.height of workpiece

mm

1200

4

Max.weight of workpiece

t

6

5

Speed change of table

r/min

2.5-80

6

Step

16

7

Feed rates

min/min

0.8-86

8

Step

12

12

9

Horizontal travel of tool post

mm

1000

Vertical travel oftool post

mm

800

10

Horizontal travel of side cutter bar

mm

630

Vertical travel of side cutter bar

mm

1000

11

Crossrail travel

mm

700

12

Max. section scale of tool bar

mm

30×40

13

Power of main motor

kw

30

revolutions

r/min

1470

14

Power of Feed motor

kw

1.3/1.7

Revolutions

r/min

940/1440

15

Machine weight

t

17.5

16

Overall dimensions(L×W×H)

mm

3100×3000×3850
