High Efficiency Steel EC 300mm Axial Fan Blower For Houses And Buildings Ventilation System with mesh stepless
High Efficiency Steel EC 300mm Axial Fan Blower For Houses And Buildings Ventilation System with mesh stepless
High Efficiency Steel EC 300mm Axial Fan Blower For Houses And Buildings Ventilation System with mesh stepless
High Efficiency Steel EC 300mm Axial Fan Blower For Houses And Buildings Ventilation System with mesh stepless
Specifications
Brand Name :
OFAN
Model Number :
ZW300C-230D3-00
Certification :
CE ROHS
Place of Origin :
China
MOQ :
1
Price :
negotiation
Supply Ability :
10000PCS
Power :
95W
Rated Speed :
1770RPM
Air Flow :
2200m³/h
Rated Current :
0.7A
Rated Voltage :
230VAC
Operation Voltage :
176-264VAC
Description

Sheet Steel Blower Fan With Refirgeration For Zw300c-230d3-00

Specifications:

Model Number:ZW300C-230D3-00

Rated Voltage:230V

Rated Speed:1770RPM

Power:95w

Rated Current:0.7A

Air Flow: 340m³/h

S Series

Material:Sheet steel

Type of protection: IP44

Approvals: CCC CE

Insulation class:B

Ball bearing:NSK

1． As the rotor is mounted to interior, the external rotor fan is more compact constructed, smaller and easy to abstract heat., thus ensure to maximum the reliability of fan operation,

2． Sustainable speed control benefits to achieve low operating costs, reduce CO2 emissions protect the environment, enable the direct, simple communication between the host controller and the system,

3． Variable speed control of EC fan can be realized / achievedvia 0-10V speed adjustment and/or external circuit impulse modulation

4． Constant torque ,constant speed and constant airflow of EC fan can be fulfilled via 180,sine SVPWM(Space Vector PWM)to meet customer needs

5． Intelligent EC fan can support users to realize centralized operation control by 485 bus and monitor as many as 255 fans

6． EC fan has comprehensive protection function, such as phase failure, overvoltage, undervoltage, locked-rotor, over current and temperature protection

High Efficiency Steel EC 300mm Axial Fan Blower For Houses And Buildings Ventilation System with mesh stepless
