Flexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOIST
Flexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOIST
Flexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOIST
Flexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOIST
Flexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOIST
Flexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOIST
Flexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOIST
Flexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOIST
Flexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOIST
Flexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOIST
Specifications
Brand Name :
ECHU/OEM
Model Number :
RVV-NBR-PUR
Certification :
CCC ISO
Place of Origin :
China
MOQ :
300M
Price :
5.88
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10000000000000KM
Delivery Time :
8WORKING DAYS
Packaging Details :
WOODEN REELS
Sheath Material :
PUR
Inner Sheath :
NBR
Insulation :
NBR
Description

Flexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOISTFlexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOISTFlexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOISTFlexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOISTFlexible Drum-Reeling Cable, Drum Cable, Reel Cable, FLEXIBLE CABLE for PASSENGER / MATERIAL HOIST

Applications:
as connecting and control cable for lift or crane, it is also used for various kinds of electric installation in dry or wet
Indoor as well as outdoor.

Properties:
the PUR outer sheath makes the cable waterproofing, oil resistance, cool resistance, abrasion resistance, Flame resistance, anti-ultraviolet.

Structure:
Conductor:superfine copper strands acc. To VDE 0295, class 5
Insulation: Butadiene-acrylonitrile rubber (NBR).
Jacket: Butadiene-acrylonitrile rubber (NBR).
Colour: various colour cores with number acc. to JISC3306 or with green/yellow.
Inner liner: non-woven fabric wrapping to release impact
Outer sheath: PUR outer sheath.(waterproofing, oil resistance, cool resistance, abrasion resistance, Flame resistance, anti-ultraviolet).
Uted insulated cable rope among cores functions as tensile resistance
the outer sheath is flame retardant and self-extinguishing
(acc. to VDE 0482, part 265-2-1 resp.EN 50265-2-1 and IEC 60332-1).

Technical data
Rated voltage:450/750V
Test voltage: 2500V
Temperature range:
fixed installation: -35 to +70
flexible application: -20 to +70
Minimum bending radius: 10X outer diameter

TYPE SPEC.
RVV-NBR-PUR 3*16+1*6
RVV-NBR-PUR 3*25+1*10
RVV-NBR-PUR 3*35+1*10
RVV-NBR-PUR 4.0*2C
RVV-NBR-PUR 4.0*3C
RVV-NBR-PUR 4.0*4C
RVV-NBR-PUR 4.0*5C
RVV-NBR-PUR 4.0*6C
RVV-NBR-PUR 4.0*7C
RVV-NBR-PUR 4.0*8C
RVV-NBR-PUR 4.0*9C
RVV-NBR-PUR 4.0*10C
RVV-NBR-PUR 4.0*11C
RVV-NBR-PUR 4.0*12C
RVV-NBR-PUR 4.0*13C
RVV-NBR-PUR 4.0*14C
RVV-NBR-PUR 4.0*15C
RVV-NBR-PUR 4.0*16C
RVV-NBR-PUR 4.0*17C
RVV-NBR-PUR 4.0*18C
RVV-NBR-PUR 4.0*19C
RVV-NBR-PUR 4.0*20C
RVV-NBR-PUR 4.0*21C
RVV-NBR-PUR 4.0*22C
RVV-NBR-PUR 4.0*23C
RVV-NBR-PUR 4.0*24C
RVV-NBR-PUR 4.0*25C
RVV-NBR-PUR 4.0*26C
RVV-NBR-PUR 4.0*27C
RVV-NBR-PUR 4.0*28C
RVV-NBR-PUR 4.0*29C
RVV-NBR-PUR 4.0*30C
RVV-NBR-PUR 6.0*2C
RVV-NBR-PUR 6.0*3C
RVV-NBR-PUR 6.0*4C
RVV-NBR-PUR 6.0*5C
RVV-NBR-PUR 6.0*6C
RVV-NBR-PUR 6.0*7C
RVV-NBR-PUR 6.0*8C
RVV-NBR-PUR 6.0*9C
RVV-NBR-PUR 6.0*10C
RVV-NBR-PUR 6.0*11C
RVV-NBR-PUR 6.0*12C
RVV-NBR-PUR 6.0*13C
RVV-NBR-PUR 6.0*14C
RVV-NBR-PUR 6.0*15C
RVV-NBR-PUR 6.0*16C
RVV-NBR-PUR 10.0*2C
RVV-NBR-PUR 10.0*3C
RVV-NBR-PUR 10.0*4C
RVV-NBR-PUR 10.0*5C
RVV-NBR-PUR 10.0*6C
RVV-NBR-PUR 10.0*7C
RVV-NBR-PUR 10.0*8C
RVV-NBR-PUR 16.0*2C
RVV-NBR-PUR 16.0*3C
RVV-NBR-PUR 16.0*4C
RVV-NBR-PUR 16.0*5C
RVV-NBR-PUR 16.0*6C
RVV-NBR-PUR 25.0*2C
RVV-NBR-PUR 25.0*3C
RVV-NBR-PUR 25.0*4C
RVV-NBR-PUR 25.0*5C
RVV-NBR-PUR 35.0*2C
RVV-NBR-PUR 35.0*3C
RVV-NBR-PUR 35.0*4C
RVV-NBR-PUR 35.0*5C
RVV-NBR-PUR 50.0*2C
RVV-NBR-PUR 50.0*3C
RVV-NBR-PUR 50.0*4C
RVV-NBR-PUR 50.0*5C
RVV-NBR-PUR 70.0*2C
RVV-NBR-PUR 70.0*3C
RVV-NBR-PUR 70.0*4C
RVV-NBR-PUR 70.0*5C
RVV-NBR-PUR 95.0*2C
RVV-NBR-PUR 95.0*3C
RVV-NBR-PUR 95.0*4C
RVV-NBR-PUR 95.0*5C
RVV-NBR-PUR 120.0*2C
RVV-NBR-PUR 120.0*3C
RVV-NBR-PUR 120.0*4C
RVV-NBR-PUR 120.0*5C
RVV-NBR-PUR 150.0*2C
RVV-NBR-PUR 150.0*3C
RVV-NBR-PUR 150.0*4C
RVV-NBR-PUR 150.0*5C
RVV-NBR-PUR 150.0*6C
RVV-NBR-PUR 185.0*2C
RVV-NBR-PUR 185.0*3C
RVV-NBR-PUR 185.0*4C
RVV-NBR-PUR 185.0*5C
