Charging Cables for Electrical Vehicles 300V EVJE 600V or 1000V EVE
Charging Cables for Electrical Vehicles 300V EVJE 600V or 1000V EVE
Charging Cables for Electrical Vehicles 300V EVJE 600V or 1000V EVE
Charging Cables for Electrical Vehicles 300V EVJE 600V or 1000V EVE
Charging Cables for Electrical Vehicles 300V EVJE 600V or 1000V EVE
Charging Cables for Electrical Vehicles 300V EVJE 600V or 1000V EVE
Charging Cables for Electrical Vehicles 300V EVJE 600V or 1000V EVE
Charging Cables for Electrical Vehicles 300V EVJE 600V or 1000V EVE
Charging Cables for Electrical Vehicles 300V EVJE 600V or 1000V EVE
Charging Cables for Electrical Vehicles 300V EVJE 600V or 1000V EVE
Charging Cables for Electrical Vehicles 300V EVJE 600V or 1000V EVE
Charging Cables for Electrical Vehicles 300V EVJE 600V or 1000V EVE
Specifications
Brand Name :
ECHU
Model Number :
300V EVJE 600V or 1000V EVE
Certification :
TUV SUD
Place of Origin :
China
MOQ :
100M
Price :
USD0.101-USD10.957/m
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10000KM/week
Delivery Time :
10day after receiving payment
Packaging Details :
splint reel/ splint box
Conductor :
Multiple stranded conductor
Application :
for connection set for conductive charging of electric vehicles
Rated Voltage :
300V, 600V, 1000V
Rated Temp :
-40-+105℃
Conductor Material :
Tinned copper or bare Copper
Conductor Type :
stranded
Insulation :
TPE
Reference Standard :
UL2263-2022
Jacket :
TPE
Flmae Test :
VW-1
Min Bending radius :
6xD
Description

Charging Cables

·Applications:
applicable to charging cables of rated voltages up to and including 300V;600V or 1000V for connection set for conductive charging of electric vehicles.

·Properties:
Conductor:Multiple stranded conductor
Insulation:TPE
Jacket:TPE

◆ PRODUCT DESCRIPTION:
lemperature range:-40℃~105℃
Rating voltage:300V,600V or 1000V Reference standard:UL 2263-2022
Flame Test:VW-1
Min Bending radius:6xD

Type Size Conductor Stranded OD mm(Ref.) Over diameter Non Shielded mm (Ref) Max.Conductor resistance mΩ/m@20℃
300EVJE 3x16AWG+1x18AWS 1.5/1.2 10.8 14.1/22.4
3x14AWG+1x18AWS 1.9/1.2 11.6 8.88/224
3x12AWG+1x18AWG 2.4/1.2 12.5 5.58/22.4
3×16AWG+2x18AWS 1.5/1.2 11.7 14.1/22.4
3x14AWG+2x18AWS 1.9/1.2 12.5 8.88/22.4
3x12AWG+2x18AWS 2.4/1.2 13.6 22.4
600V or 1000V EVE 2×8AWG+10AWG 4.5/3.2 21.5 2.23/3.51
2×6AWG+8AWG 5.5/4.5 24.5 1.40/2.23
2x4AWG+6AWG 6.7/5.5 28 0.882/1.4
2×2AWG+4AWG 8.5/6.7 31.2 0.555/0.882
3x16AWG+1×18AWG 1.5/1.2 12 14.1/224
3×14AWG+1×18AWG 1.9/1.2 14.1 8.88/22.4
3×12AWG+1×18AMG 2.4/1.2 15 5,58/22.4
3×10AWG+1×18AWG 3.0/1.2 16.4 3.51/224
2×8AWG+10AwG+18AWG 4.5/3.2 21.5 2.23/3.51/22.4
2×6AWG+8AWG+18AWG 5.5/4.5 24.1 1.40/2.23/22.4
2x4AWG+6AWG+18ANG 6.7/5.5 28.5 0.882/1.4/22.4
2×2AWG+4AWG+18AWG 8.2/6.6 31 0.555/0.882722.4
3×16AWG+2×18AWG 1.5/1.2 13 3.51/224
3×14AWG+2×18AWG 1.9/1.2 14,5 8.88/22.4
3×12AWG+2x18AWG 2.4/1.2 16 5.58/22.4
3×10AWG+2×18AWG 3.0/1.2 16.5 3.51/22.4
2×8AWG+10AWG+2x16AWG 4.5/3.2 21.6 2.23/3.51
2×6AWIG+8AWG+2x18AWG 5.5/4.5 24 1.40/2.23
2x4AWG+6AWG+2×184WG 6.7/5.5 28.2 0.882/1.4
2×2AWG+4AWG+2×18AWG B2/6.6 31 0.555/0.882
2×1/0AWG+2AWC 10.5/8.2 39,5 0.349/0.555
2×3/0AWG+1/0AWS 13.05/10.5 46.8 0.219/0.349
