ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color
ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color
ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color
ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color
ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color
ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color
ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color
ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color
ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color
ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color
ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color
ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color
Specifications
Brand Name :
ECHU
Model Number :
UL1283
Certification :
UL
Place of Origin :
China
MOQ :
100meters
Price :
USD0.305-USD3.397/M
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10000km per week
Packaging Details :
in roll or splint reel
Conductor :
Copper or tinned copper
Voltage :
600V,
Color :
Different Colors
Temperature :
105 ℃
Insulation :
Double Insulation
Description

ECHU UL CABLE Certified ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color

Production description:

UL CERT.:E312831

Single Conductor Single Core Flexible Wire UL1283 PVC Insulated 8 AWG,7AWG,6AWG,5AWG,4AWG,3AWG,2AWG

Construction
Conductor :bare copper or tinned copper conductor
Insulation: PVC
Standards
International: UL758 , UL1581
RoHS,REACH Compliant,
Technical data
Rated voltage:600V
Rated Temperature:105℃
Flame: VW-1, FT1, FT2
Oil resistance: 60 ℃ or 80 ℃ Oil
Voltage withstand test:AC 2.5kV/1min

ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color

ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color

ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color

ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color

ECHU UL CABLE ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color

TYPE
Spec. AWG
Bare Copper
Tinned Copper
Insulation Thickness mm
Weight KG/KM
Conductor No.
Conductor Dia.
Conductor No.
Conductor Dia.
UL1283
8
118
0.3
118
0.30
1.52
119.5
UL1283
7
147
0.3
147
0.30
1.52
141.8
UL1283
6
189
0.3
189
0.30
1.52
173.4
UL1283
5
238
0.3
238
0.30
1.52
209.7
UL1283
4
299
0.3
299
0.30
1.52
254.3
UL1283
3
378
0.3
378
0.30
1.52
311.2
UL1283
2
475
0.3
475
0.30
1.52
380.2
