Specifications
Brand Name :
ECHU
Model Number :
UL1061
Certification :
UL. E312831
Place of Origin :
China
MOQ :
305M
Price :
0.0132-0.0397USD/M
Packaging Details :
305meter per roll
Payment Terms :
T/T, Western Union
Supply Ability :
10000KM/Week
Product Name :
UL1061 Electrical wire
Conductor :
bare copper or tinned copper
Colors :
12 different kinds of Color
Company type :
Manufacturer
Range of Application :
Internal Wiring
Brand :
ECHU
Voltage :
300V
Description

UL1061 Sr-PVC Insulated Copper Wire Electronic Wire & Cable, LED Light

Product Description:
★ Rated temperature: 80ºC
Rated voltage: 300V
★ Reference Standard: UL Subject 758, UL1581 & CSA C22.2 NO.210.2
★ Tinned or bare, stranded or solid copper conductor,30-16 AWG
★ Colour-coded lead free SR-PVC insulation
★ Uniform insulation thickness to ensure easy stripping and cutting
★ Passes UL VW-1 & CSA FT1 vertical flame test
★ Application: For internal wiring of electronic and electrical equipment,
protection is required where mechanical damage is possible

This type of cable have the advantage of the cable have smaller outside diameter, can meet higher using requirement.

26AWG UL1061 Tinned Copper Electrical Wire UL RoHS Certificate Hook up Wire 300V in Red Color

26AWG UL1061 Tinned Copper Electrical Wire UL RoHS Certificate Hook up Wire 300V in Red Color

26AWG UL1061 Tinned Copper Electrical Wire UL RoHS Certificate Hook up Wire 300V in Red Color

26AWG UL1061 Tinned Copper Electrical Wire UL RoHS Certificate Hook up Wire 300V in Red Color

Conductor Insulation Maximum Resistance at 20ºC
Ω/km
AWG No./mm Dia.
mm		 Nom. Thick.
mm		 Nom.Dia.
mm
30 7/0.1 0.30 0.26 0.82 354
28 7/0.127 0.38 0.26 0.90 223
26 7/0.16 0.48 0.26 1.00 139
24 11/0.16 0.61 0.27 1.15 88.9
22 17/0.16 0.76 0.26 1.28 57.5
20 26/0.16 0.94 0.26 1.46 34.6
18 41/0.16 1.18 0.26 1.70 23.3
16 26/0.254 1.49 0.26 2.02 15.1
