ECHU UL ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 300kcmil with Black Color
ECHU UL ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 300kcmil with Black Color
ECHU UL ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 300kcmil with Black Color
ECHU UL ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 300kcmil with Black Color
ECHU UL ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 300kcmil with Black Color
ECHU UL ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 300kcmil with Black Color
ECHU UL ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 300kcmil with Black Color
ECHU UL ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 300kcmil with Black Color
ECHU UL ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 300kcmil with Black Color
ECHU UL ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 300kcmil with Black Color
Specifications
Brand Name :
ECHU
Model Number :
UL1284
Certification :
UL
Place of Origin :
China
MOQ :
100meter
Price :
USD0.302 to USD9.255/m
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10000km per week
Packaging Details :
in roll or splint reel
Color :
Black/red/....
Voltage :
600V
Temperature :
105℃
Condutor :
Bare copper or tinned copper
Description

ECHU UL ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 300kcmil with Black Color

Product Description:

UL CERT.:E312831

UL1284: 1AWG, 2AWG, 3AWG,4AWG,5AWG,6AWG,7AWG,8AWG, 1/0AWG,2/0AWG, 3/0 AWG, 4/0AWG, 250Kcmil, 300kcmil,350kcmil, 400kcmil,450kcmil,500kcmil,500kcmil

Construction
Conductor :bare copper or tinned copper conductor Insulation: PVC
Standards
International: UL758 , UL1581
RoHS,REACH Compliant,
Technical data
Rated voltage:600V
Rated Temperature:105℃
Flame: VW-1, FT1, FT2
Oil resistance: 60 ℃ or 80 ℃ Oil
ECHU UL ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 300kcmil with Black ColorECHU UL ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 300kcmil with Black Color
TYPE
Spec. AWG
Bare Copper
Tinned Copper
Insulation Thickness mm
Weight KG/KM
Conductor No.
Conductor Dia.
Conductor No.
Conductor Dia.
UL1284
8
118
0.3
118
0.30
2.03
138.4
UL1284
7
147
0.3
147
0.30
2.03
161.8
UL1284
6
189
0.3
189
0.30
2.03
194.9
UL1284
5
238
0.3
238
0.30
2.03
232.8
UL1284
4
299
0.3
299
0.30
2.03
279.0
UL1284
3
378
0.3
378
0.30
2.03
337.9
UL1284
2
475
0.3
475
0.30
2.03
409.1
UL1284
1
600
0.3
600
0.30
2.03
499.6
UL1284
1/0
251
0.52
272
0.50
2.03
609.7
UL1284
2/0
317
0.52
343
0.50
2.03
749.9
UL1284
3/0
400
0.52
433
0.50
2.03
924.3
UL1284
4/0
505
0.52
546
0.50
2.03
1142.9
UL1284
250
598
0.52
647
0.50
2.41
1372.4
UL1284
300
716
0.52
774
0.50
2.41
1617.7
UL1284
350
833
0.52
901
0.50
2.41
1859.5
UL1284
400
955
0.52
1033
0.50
2.41
2110.4
UL1284
450
1073
0.52
1161
0.50
2.41
2352.2
UL1284
500
1191
0.52
1288
0.50
2.41
2593.1
UL1284
550
1313
0.52
1420
0.50
2.79
2894.1
