Specifications
Brand Name :
ECOGRACE
Model Number :
FP 1250
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1SET
Price :
4000 -20000 USD
Payment Terms :
D/P, Western Union, MoneyGram, T/T, L/C
Supply Ability :
100 SET/ MONTH
Delivery Time :
4-8 WEEKS
Packaging Details :
Pallet in Container
Filter Area :
125 M2
No. of filter chamer :
48
Total Volume :
1.935 m3
Thickness of filter plate :
65mm
Thickness of cake :
30mm
Pressure :
1.2 Mpa
Application :
Waste water , Sewage , Mining
Description

Chamber / Membrane Filter Press FP1250 Waste Water Treatment 200 M2 Filter Press

Mining and Mineral Process Automatic Filter Press FP 1000 Chamber Filter Press

Filter Press Equipment :
1 . Filter Pressure 1.0 to 1.6Mpa
2 .Filter Area 11 to 125 sqm
3 Automatic shifting and discharging cake

FP 1250 Automatic Filter Press Chamber Filter Press / Membrane Filter Press
1. Automatic hydraulic compressing, automatic maintaining pressure
2. Relay control
3. Electric controlling cabinet is combined with hydraulic station
4 Max.Filter temperature 120 centi degree
5. Automatic shifting and discharging
6. SUS slide way
7. Steel structure
8. Raw reinforced polypropylene filter plate
9. The side bar is made from Q235-A solid steel plate

Technical parameter:
Filter Area(m2) 100 112 125 140 160 180 200 224 250 260
Thickness of cake(mm) 30 30 30 30 30 30 30 30 30 30
Volume ( M3 ) 1.53 1.695 1.935 2.1 2.42 2.745 3.065 3.39 3.795 4.105

Components

Item No. Description Manufacturer
1 Motor of hydraulic station ABB
2 Major electric components Schneider
3 Hydraulic valve, Local
4 Filter cloth ECOGRACE



Applicable field

1.) Metallurgy, Mining & Mineral , coal
Gold, silver, copper, zinc ore mineral powder, coal washing , tailing coal
Aggregate , Asphalt , Limestone , Gypsum , etc

2) Chemical
Coating, paint, silica, caustic soda, soda ash, alkali, salt mud, new, water purification machines (aluminum, aluminum polymerization acetylacetonate, gypsum, insurance, phosphor, lithopone)


3)Sewage
Printing and dyeing wastewater, sewage, smelting, leather, pharmacy sewage water brew, electroplating wastewater, sewage and waste, chemical electrolysis of water environment

4 )Foods
Vegetable oil, monosodium glutamate, glucose, starch sugar, plant sweet, maltose, starch, maize, rice, Joan, seaweed, kara glue, milk, oral liquid, beer yeast, soy sauce, rice wine, white wine, fruit juice, beverage, plant protein, and spices

5) Pottery clay
Bentonite, electronic ceramic soil, kaolin, active soil, porcelain clay, limestone, granite furnaces

6) Petroleum
Diesel oil, sesame oil, shortening dewaxing etc

Chamber / Membrane Filter Press FP1250 Waste Water Treatment 200 M2 Filter Press
