Paper Mill Air Pollution Control System Dust Collector Filter Bag Baghouse Filter
Paper Mill Air Pollution Control System Dust Collector Filter Bag Baghouse Filter
Paper Mill Air Pollution Control System Dust Collector Filter Bag Baghouse Filter
Paper Mill Air Pollution Control System Dust Collector Filter Bag Baghouse Filter
Specifications
Brand Name :
ECOGRACE
Model Number :
FG-130x3000
Certification :
SGS,ISO
Place of Origin :
Zhejiang, China
MOQ :
100 pcs
Price :
USD$18-35/pcs
Payment Terms :
L/C, D/A, T/T, Western Union, MoneyGram, D/P
Supply Ability :
5000 pcs per week
Packaging Details :
In cartons
Fiber :
Fiberglass filter bag
Weight :
775 gsm
Length :
2000-8000mm
Application :
Cement plant Paper Mill
Working temperature :
260degree
Usage :
Dust Filter,Air filter
Material of bag :
Non-woven,Polyester,PPS,Fiberglass,aramid
Description
Paper Mill Coal Boiler Dust Filtration Fiberglass Filter Bag ( 160 x 6000)
Dust Filter bag applied for Cement Plant Kiln , Paper Mill Boiler , Ferro Alloy filtration system , etc.

Fiberglass Filter Bags Specification:
1. Material : Fiberglass staple fiber
2. Scrim: with fiberglass staple yarn
3. Width:≤2.2m
4. Thickness:2.3-2.7mm
5. Weight:800-900g/m2 ±10%
6. Temperature (ºC): Continue: 240, Instant: 280

Fiberglass Filter Bags Applications :
Fiberglass non woven filter media bags applications ranges in asphalt plant, incinerator, metallurgy, cement carbon black, liquid boiler, coal fire boiler dust filtration.

Fiberglass Filter Bags Advantages :

1. Good Temperature-Resistance. Max. Temp. 280 degree C.
2. High Filtration Efficiency: up to 99.9%
3. Excellent performance in Anti corrosion.
4.Fiberglass filters is the first choice for incinerator smoke , smoke in industries like metallurgy, cement , carbon black, liquid boiler, coal fire boiler.
5. Longer working time: more than 36 months.
6. Variety of finish treatments : Coating PTFE Membrane ,PTFE Impregnation
7. Good heat resistance, flame retardant, anti-corrosion effect.
8 . Used in dust filtration of high temperature, high acidity, high alkalinity, fine high
temperature, collection of valuable metal powder , high adhesive property etc.
9. . Customized by order.
With rich practical experience and working R&D team, we can design and develop kinds of filter media to satisfy the complex and diverse working conditions.
10. Advanced production lines: Complete testing and testing methods are the assurance to the products' quality.

Paper Mill Air Pollution Control System Dust Collector Filter Bag Baghouse Filter

Fiberglass Filter Bags Physical Properties :

Weight(gsm) 850
Thickness(mm) 2.5
Width(mm) ≤2.2m
Finish treatment Singeing, Calendering, Heat setting
Air permeability(L/m2.s) 200-350
Tensile strength(N/5cm) warp ≥900
weft ≥1050
Tensile elongation(%) warp ≤35
weft ≤60
Heat shrinkage(%) warp ≤1.5
weft ≤1.0
Temperature(ºC) Continue 240
Instant 280


Fiberglass Filter Bags Chemical Properties:

Anti-acid Excellent
Anti-alkali Excellent
Anti-abrasion Excellent
hydrolysis stability Good
