WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
Specifications
Model NO. :
B13
Heat Source Type :
Air Source Heat Pump
Operating Air Temperature :
-5~43
Heat Capacity :
4.5kw-31kw
Condenser :
Titanium Coil
Compressor :
Rotary
Power Supply (V/Hz) :
220-240V/1pH/50Hz
Application :
Villa Family, Sauna and Swimming Pool, Hotels, Gym
Transport Package :
Factory Standard
Specification :
755*258*500mm
Trademark :
Wotech
Origin :
China
HS Code :
84186120
Customization :
Available
Certification :
RoHS, CB, CCC, ISO9001, CE
Working Medium :
R32
Description
26KW R32 Environmental Friendly Air Source Swimming Pool Heat Pump with WiFi APP
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
Features:
1.Anti-UV Plastic ABS corrosion resistant casing
2.High COP.
3.Patented corrosion resis ant titanium exchanger
4.Environmental friendly
5.LCD or colorful LED controller for options.
5.Re-start memory
6.Heating and cooling with reversible defrosting.
7.Super quiet
8.WIFI APP control(optional)
9.Suitable for Koi ponds as well as swimming pools or sauna or SPA.
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
Technical Parameter:
CODE WP05 WP06 WP08 WP10 WP12 WP14 WP17M
Advised pool size (m3) 7~14 8~16 10~20 14~28 17~34 20~40 25~50
Heating Performance Condition: Air 24ºC, Water 26ºC
Heating Capacity (KW) 4.5 5.1 7 9.8 11.2 13.2 16.8
COP 5 5.15 5.07 5.08 5.3 5.35 5.4
Heating Performance Condition: Air 15ºC, Water 26ºC
Heating Capacity (KW) 3.65 3.9 5.2 7.6 8.7 10.2 13.5
COP 4.2 4.32 4 4.11 4.55 4.6 4.5
Operating Air Temperature ºC -5~43
Power Supply (V/Hz) 220-240V/1PH/50HZ
Rated Input Power(KW) 0.86 0.99 1.34 1.95 2.11 2.47 3.11
Rated Input Current(A) 4.1 4.3 6.4 9.3 10.1 11.4 14.8
Max Heating Current (A) 5.8 5.9 8.9 12.7 13.1 14.8 19.2
Water Flow Rate (m3/h) 1.9 2.4 3.4 4.1 5.4 6 7.3
Water Connection ( inch) 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2
Sound level at 1m (dB(A)) 49 53 59 58 52 53 57
Net Dimension L*W*H(mm) 755*258*500 937*286*550 937*286*550 1012*307*614 1012*307*614 1012*307*614 1117*396*703
Qty per 20ft/40HQ(PCS) 176/445 128/264 128/264 90/248 90/248 90/248 42/132
CODE WP17 WP21 WP26 WP31
Advised pool size (m3) 25~55 30~60 35~70 45~90
Heating Performance Condition: Air 24ºC, Water 26ºC
Heating Capacity (KW) 17.4 20.2 24.3 30
COP 5.84 5.98 5.69 5.71
Heating Performance Condition: Air 15ºC, Water 26ºC
Heating Capacity (KW) 13.9 17.5 19.8 23.5
COP 4.79 4.75 4.66 4.77
Operating Air Temperature ºC -5~43
Power Supply (V/Hz) 380V/3PH/50HZ
Rated Input Power(KW) 2.9 3.26 4.01 5.25
Rated Input Current(A) 5.2 5.8 7.2 8.8
Max Heating Current (A) 6.8 7.7 9.8 12
Water Flow Rate (m3/h) 7.3 9 11.2 13.3
Water Connection ( inch) 1-1/2 1-1/2 1-1/2 1-1/2
Sound level at 1m (dB(A)) 57 57 60 60
Net Dimension L*W*H(mm) 1117*396*703 1117*396*1053 1117*396*1053 1117*396*1053
Qty per 20ft/40HQ(PCS) 42/132 42/88 42/88 42/88
Key Components:
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
Wotech Project Cases:
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
Manufacturing & Laboratories:
WiFi Controlled 26kw R32 Swimming Pool Heat Pump Environmentally Friendly and Suitable for Operating Air Temperature of -5-43
