Automatic Slitting Rewinding Machine For Thermal Paper Ecoographix 110m/Min
Automatic Slitting Rewinding Machine For Thermal Paper Ecoographix 110m/Min
Automatic Slitting Rewinding Machine For Thermal Paper Ecoographix 110m/Min
Automatic Slitting Rewinding Machine For Thermal Paper Ecoographix 110m/Min
Automatic Slitting Rewinding Machine For Thermal Paper Ecoographix 110m/Min
Automatic Slitting Rewinding Machine For Thermal Paper Ecoographix 110m/Min
Specifications
Brand Name :
EcooGraphix
Model Number :
Ecoo T-900
Certification :
CE; ISO
Place of Origin :
China
MOQ :
1SET
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
500 Sets/ Year
Packaging Details :
Standard Exporting Package: Polywood Carton
Product Name :
Automatic Slitting Rewinding Machine
Max. Unwinding Width :
900 mm
Max. Unwinding Dia :
1000 mm
Max. Rewinding Dia :
270 mm
Min Slitting Width :
25 mm
Max. Machine Speed :
110 m/min
Main Power :
2.95 kw
Unwinding Shaft :
3'' (76mm) air expanding shaft
Rewinding Shaft :
0.5'', 1'' or as your request
Weigth :
300m/Min
Min. Slit Width :
1300 kg
Demension :
2000*1700*1500 mm
Description

Ecoographix Automatic Slitting Rewinding Machine For Thermal Paper

Product Description

Brief introduction

Thermal roll slitting machine is used for slitting and winding all kinds of thermal paper, including fax paper, ATM paper, ECG paper, medical record paper, self-adhesive trade marks, non-woven cloth, films etc.

Features

10000 rolls per 8h on average
Siemens PLC control system
Automatic motor-driven chain lifts jumbo roll up or down
Redline marking system

Automatic Slitting Rewinding Machine For Thermal Paper Ecoographix 110m/Min

Specification

​​​​​​​Model

Ecoo T-900

Max. Unwinding Width
900 mm
Max. Unwinding Dia
1000 mm
Max. Rewinding Dia
270 mm
Min Slitting Width
25 mm
Max. Machine Speed
110 m/min
Main Power
2.95 kw
Unwinding Shaft
3'' (76mm) air expanding shaft
Rewinding Shaft
0.5'', 1'' or as your request
Weigth
1300 kg
Demension
2000*1700*1500 mm
Model Ecoo T-900
Max. Unwinding Width 900 mm
Max. Unwinding Diameter 1000 mm
Max. Rewinding Diameter 270 mm
Min. Slitting Width 25 mm
Max. Machine Speed 110 m/min
Main Power 2.95 Kw
Unwinding Shaft 3'' (76mm) air eapanding shaft
Rewinding Shaft 0.5'', 1'' or as your request
Weight 1300 kgs
Dimension 2000*1700*1500 mm

Machine Spare Parts

Unwinding Section
- Chain link automatic lift-up loading system
- 3''(76mm)air expanding shaft
- Floating roller constant tension
- Two set Sensor

Slitting Section
- Disc cutter
- Disc Cutter Assembly adopts the cam self-locking
- Cutter with adjustable and moveable blade base
- Meter counter
Rewinding Section
- 0.5",1",1.5" or as your request
- Center Rewinding technology
- Pressure roller
- Automatic Tucker

Controlling Section
- Siemens PLC & HMI from Germany
- All the parameters are displayed on the monitor
- Low voltage electrical appliances all from S chneider

Trimmed Waste Edge
- Edge Waste Blower with Expulsion Tube

Optional
- Automatic Paper Core Loader
- Automatic Cutting & Gluing Device
- Automatic Roll Cut Off & Hammer Unit
- Whole Packing Line for Thermal Rolls
Producing And Packaging

Automatic Slitting Rewinding Machine For Thermal Paper Ecoographix 110m/Min

Automatic Slitting Rewinding Machine For Thermal Paper Ecoographix 110m/Min

Automatic Slitting Rewinding Machine For Thermal Paper Ecoographix 110m/Min

More Details

Automatic Slitting Rewinding Machine For Thermal Paper Ecoographix 110m/Min

Automatic Slitting Rewinding Machine For Thermal Paper Ecoographix 110m/Min

FAQ

1. What are your main products?
We Ecoographix is a specialized supplier of printing machines and consumables. We cover both digital printing and offset printing,
including prepress, pressroom and post press, focusing on packaging printing and book printing.
We have hundreds of users all over the world. We bring forward top quality of Chinese printing products to meet diversified printing requirements.

2. Where is your factory?
Our sale office is in Hangzhou, one hour by train away from Shanghai. Our factories are in Shanghai, Wenzhou, Suzhou and Nanyang.

3. What is your warranty?
One year for machine and printing head if use our ink. One year for machine only if do not use our ink.

4. What is the Lead Time?
Usually 30 days, and we will try our best to meet your demands.

5. What about the Installation and after-sales technician support?
Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge
and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours.
