Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min
Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min
Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min
Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min
Specifications
Brand Name :
EcooGraphix
Model Number :
ECOO ZBS 320
Certification :
ISO9000, CE
Place of Origin :
China
MOQ :
1 SET
Payment Terms :
L/C, T/T
Supply Ability :
500 Sets/Year
Delivery Time :
45 Days
Packaging Details :
Standard Export Packing
Price :
Negotiable
Classification :
Label Printing Machine
Precision of Chromatography :
± 0.1mm
Printing Length :
177.8-355.6mm
Max. Printing Width :
310mm
Max. Unwinding Diameter :
600mm
Max. Rewinding Diameter :
600mm
Printing Colour :
1-6 colors
Description

Automatic Flexographic UV Label Printing Machine

With Die-cutting Station

------------------------------------------------------------------------------------------------------------------------------------------------

▶ Label Printing Machine Features

1. Ceramic anilox cylinder.

2. Magnetic powder brake/clutch.

3. 360°plate adjustment printing units.

4. Hot air dryer printing units.

5. One die-cutting station.

6. Separated ink rollers.

7. Inverter main motor.

8. The machine can finish material-feeding, printing, varnishing, drying, laminating, rewinding and die-cutting in a lump.

------------------------------------------------------------------------------------------------------------------------------------------------

▶​ Specification

Automatic Flexographic Label Printing Machine

Model
ECOO-320

Printing speed
60 m/min

Printing color
1-6 colors

Max. web width
320mm

Max. printing width
310mm

Max. unwinding diameter
600mm

Max. rewinding diameter
600mm

Printing length
177.8-355.6mm

Precision of chromatography
± 0.1mm

Dimensions(L×W×H)
2000 x 1100 x 2600mm

Machine weight
About 2150kgs

​

Automatic Flexographic Label Printing Machine
Model ECOO-320
Printing speed 60 m/min
Printing color 1-6 colors
Max. web width 320mm
Max. printing width 310mm
Max. unwinding diameter 600mm
Max. rewinding diameter 600mm
Printing length 177.8-355.6mm
Precision of chromatography ± 0.1mm
Dimensions(L*W*H) 2000 x 1100 x 2600mm
Machine weight About 2150kgs

​

------------------------------------------------------------------------------------------------------------------------------------------------

▶​ Main Configuration

​

MAIN CONFIGURATION

Description Brand Quantity Origin
Printing roller   3 sets China
Anilox roller Auclean/Laser 1 set China
Unwind tension controller Mitsubishi 1 set Japan
Rewind tension controller ZXTEC 1 set China
Main motor Wannan 1 set China
Transducer Mitsubishi 2 sets Japan
Magnetic power brake/cluth Ningxia 3 sets China
Electromagnetic valve Airtac 2 set Taiwan
Inverter Schneider 1 set France
AC Contactor Schneider 2 pcs France
Time relay C-LIN 1 pc China
Solid relay Omron 6 pcs Japan
Micro relay Weidmiiller 2 pcs Germany
Temperature Controller Yuyao 6 pcs China
Air switches Siemens 8 pcs Germany
Low pressure wiring Schneider All France
All the bearing NSK/ CHINA   JAPAN/ CHINA

​

------------------------------------------------------------------------------------------------------------------------------------------------

▶​ Producing And Packaging

From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.

Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min

Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min

Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min

Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min

Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min

Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min

Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min

Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min

Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min

------------------------------------------------------------------------------------------------------------------------------------------------

▶​ Certifications

Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min

Automatic Flexographic Label Printing Machine With Die Cutting Station 60m/min

------------------------------------------------------------------------------------------------------------------------------------------------

▶​ FAQ

Q1: What are your main products ?

A: Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP, Flexo CTP, Processor, Offset Plates, Offset Inks, Offset Printing Blankets, Postpress Packing Equipment and so on.
You can get the equipment and consumables all in one and no worry about the after-sales service from our company.

Q2: Where is your factory ?

A: Our CTP Processor machine factory is in Shanghai, you are warmly welcome to visit our factory!

Q3: How long is the lead time ?

A: The lead time is normally 30 days. We can accelerate for emergency cases.

Q4: Is there any certification for your machine ?

A: Yes, all our machines have been certified by SGS and CE.


Q5: How long is the warranty period ?

A: EcooGraphix guarantees 1 year of warranty for laser head and spare parts.

Q6: What is your normal payment term ?

A: Normally, 30% TT deposit, 70% before shipping, or LC at sight.
Q7: What about the installation and after-sales technician support ?

A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets, service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP installations worldwide, there are also many end users(printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular onsite visits.
These end users printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintanence. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hassle on installations, training and after sales service. We guarantee your satisfaction.
