16PPH UV-CTP Plate Machine Automatic UV CTP Platesetter
16PPH UV-CTP Plate Machine Automatic UV CTP Platesetter
Specifications
Brand Name :
EcooGraphix
Model Number :
UV-800 (F, S, E) A
Certification :
ISO9000, CE
Place of Origin :
China
MOQ :
1 SET
Payment Terms :
L/C, T/T
Supply Ability :
1000 Sets/Year
Delivery Time :
30 Days
Packaging Details :
Standard Export Packing
Price :
Negotiable
Machine Type :
UV-CTP Plate Machine
Media Type :
Positive UV-CTP Plate, High-Sensitive PS Plate
Imaging System :
64CH, 48CH, 32CH, Discrete 400-410nm Laser Diode
Throughput :
28pph, 22pph, 16pph, 1030mm X 800mm, 2400dpi
Repeatability :
±5 μm(Continuous exposing for 4 times or above on the same plate with a temperature of 23℃ and humidity of 60%)
Resolution :
2400dpi(Option: 1200dpi)
Interface :
USB 2.0
Machine Size (WxLxH)mm :
2127 X 1610 X 1058
Description

16PPH-28PPH Automatic CTCP(UV-CTP) Platesetter Offset Plate Machine

--------- ○ --------- ○ Application ○ --------- ○ ---------

EcooGraphix Conventional CTP(UV-CTP/CTCP) Plate Making Machine is the first Prepress necessity of quick short-run offset printing. It can output the images on the computer to printing CTP plate directly through the CTP machine and save the film and labor.

By the EcooGraphix CTP, the customer can get excellent output image quality, highly reliable stability, less space occupied with more flexibility.

EcooGraphix UV-800 A series Conventional CTP are for A1 or B1 paper size newspaper or commercial printing with the output speed 16PPH to 28PPH. The A series are automatic online CTP machines, can be connected with Autoloader, Bridge and Processor.


--------- ○ --------- ○ Specification ○ --------- ○ ---------

ECOO UV-800 Series Automatic CTP Machine(Online System)

Model
UV-800FA, UV-800SA, UV-800EA

Exposing Method
External Drum

Imaging System
64-channel, 48-channel, 32-channel, Discrete 400-410nm laser diode

Throughput
28PPH, 22PPH, 16PPH, 1030mm x 800mm, 2400dpi

Plate Sizes
Max. 1163mm x 940mm, Min. 400mm x 300mm (300mmx250mm is available)

Exposing Size
Max. 1130mm x 884mm

Media Type
Positive UV-CTP plate, high-sensitive PS plate

Plate Thickness
0.15mm to 0.30mm

Resolution
2400dpi(Option: 1200dpi)

Repeatability
± 5μm(Continuous exposing for 4 times or above on the same plate with

a temperature of 23ºC and humidity of 60%)

Interface
USB 2.0

Plate Loading
Semi automatic

Net Weight
1200kg

Machine Size(WxLxH)mm
2127 × 1610 × 1058

Power Supply
Single phase: 220AC, +6%, -10%, Power Consumption: 4KW

Environment
Recommended: 21-25ºC, Max. 15-30ºC, Humidity: 40-70%
​

ECOO UV-800 Series Automatic CTP Machine(Online System)
Model UV-800FA UV-800SA UV-800EA
Exposing Method External Drum
Imaging System 64-channel 48-channel 32-channel
Discrete 400-410nm laser diode

Throughput
 		 28PPH 22PPH 16PPH
1030mm x 800mm, 2400dpi
Plate Sizes Max. 1163mm x 940mm
Min. 400mm x 300mm (300mmx250mm is available)
Exposing Size Max. 1130mm x 884mm
Media Type Positive UV-CTP plate, high-sensitive PS plate
Plate Thickness 0.15mm to 0.30mm
Resolution 2400dpi(Option: 1200dpi)
Repeatability

± 5μm(Continuous exposing for 4 times or above on the same plate with

a temperature of 23ºC and humidity of 60%)
Interface USB 2.0
Plate Loading Semi automatic
Net Weight 1200kg
Machine Size(WxLxH)mm 2127 * 1610 * 1058
Power Supply Single phase: 220AC, +6%, -10%, Power Consumption: 4KW
Environment Recommended: 21-25ºC, Max. 15-30ºC, Humidity: 40-70%

​

--------- ○ --------- ○ Producing And Packaging ○ --------- ○ ---------


From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.

16PPH UV-CTP Plate Machine Automatic UV CTP Platesetter

16PPH UV-CTP Plate Machine Automatic UV CTP Platesetter

16PPH UV-CTP Plate Machine Automatic UV CTP Platesetter

16PPH UV-CTP Plate Machine Automatic UV CTP Platesetter

16PPH UV-CTP Plate Machine Automatic UV CTP Platesetter

16PPH UV-CTP Plate Machine Automatic UV CTP Platesetter

16PPH UV-CTP Plate Machine Automatic UV CTP Platesetter

--------- ○ --------- ○ Certificates ○ --------- ○ ---------

16PPH UV-CTP Plate Machine Automatic UV CTP Platesetter

16PPH UV-CTP Plate Machine Automatic UV CTP Platesetter

--------- ○ --------- ○ FAQ ○ --------- ○ ---------

​



1) What are your main products ?


A: Our main products are the Prepress CTP System(4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP and CTCP, Flexo CTP, Processor), and Post Press Packing Equipments(Laminating Machine, Foil Stamping and Die Cutting Machine, Paper Box Window Patching Machine, Book Binding Machine and so on) and the Printing Consumables(Offset Printing Plates, Inks, Printing Blankets, Plate Dot Densimeter).


Our partners in USA, Canada, Mexico, Colombia, Turkey, Hungary, South Africa and so on are very pleased with our technician support service and product performance. You can get the Pre-press and Post Press equipments and consumables all in one and no worry about the after-sales service from our company.






2) Where is your factory ?


A: Our CTP machine factory is located in Hangzhou city, which is about 1.5 hours by train from Shanghai. You are warmly welcome to visit our factory!






3) What is your warranty for the CTPs ?


A: Three years' Laser Head and main spare parts for the CTPs, one year for the Processor.






4) What is the lead time ?


A: Usually 20-30 days, and we will try our best to meet your demands.






5) Can you also supply the Workflow and RIP ?


A: Yes, we can provide the Workflow Brain New and RIP Compose V9. Machine price does not include software.




6) What about the installation and after-sales technician support ?

A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets, service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP installations worldwide, there are also many end users(printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular on site visits.

These end users printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintenance. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hassle on installations, training and after sales service. We guarantee your satisfaction.


​
