50x50x5 304 Angle Steel For Structural Brackets
50x50x5 304 Angle Steel For Structural Brackets
50x50x5 304 Angle Steel For Structural Brackets
50x50x5 304 Angle Steel For Structural Brackets
50x50x5 304 Angle Steel For Structural Brackets
50x50x5 304 Angle Steel For Structural Brackets
50x50x5 304 Angle Steel For Structural Brackets
50x50x5 304 Angle Steel For Structural Brackets
Specifications
Brand Name :
EDEST STEEL
Model Number :
Stainless Steel Angle
Certification :
ISO,PE, MTC BV SGS
Place of Origin :
China
MOQ :
1ton
Price :
$1030-$1480 /Ton
Payment Terms :
L/C, T/T
Supply Ability :
5000 Ton/Tons per Month
Delivery Time :
3-5 work days
Packaging Details :
Waterproof and rust-proof seaworthy packaged goods according to customer requirements
Application :
Beams, bridges, transmission towers
Processing Service :
Bending, Welding, Decoiling, Punching, Cutting
Type :
Equal
Surface Finish :
bright, polished, annealed & pickled
Standard :
AISI, ASTM, DIN, EN, GB, JIS
Product name :
Stainless Steel Angle Bar
Shape :
Angle
Technique :
Hot Rolled
Thickness :
20*20-200*200 mm Or customized
Key Word :
stainless steel angle bar
Package :
Standard Sea-worthy Packing
Length :
6m-12m
Stock :
in warehouse
Keyword :
stainless steel angle
Description

structural frame 304 angle punching cutting welding stainless steel angle

Material characteristics:

Stainless steel gives angle steel good corrosion resistance, and it can be used for a long time in a humid and chemically corrosive environment without rusting


In the fields of chemical industry, marine engineering, etc., 50x50x5 stainless steel angle steel can be used to build structural frames, support equipment, etc.

It has high strength and hardness and can withstand large pressure, tension and impact. This makes it an important load-bearing component in the fields of building structure, machinery manufacturing, etc.

It is easy to perform processing operations such as cutting, welding, drilling, stamping, bending, etc., and is convenient for customization and installation according to actual needs

The surface is smooth and bright, with good decorative properties, and can be used in some places with high requirements for appearance, such as building decoration, interior decoration, etc.

It is generally produced by hot rolling process, that is, after the low-carbon square steel billet is heated to a high temperature state, it is rolled through a rolling mill to form it into the shape of an equilateral angle steel. The finished product is usually delivered in hot-rolled, normalized or hot-rolled state

Uses:

Widely used in building structures, such as beams, bridges, transmission towers, lifting and transportation machinery, ships, industrial furnaces, reaction towers, container racks, warehouse shelves, etc.


In some large-scale construction projects, it can be used as a support for the frame structure to ensure the stability and safety of the building


Used to manufacture parts of various mechanical equipment, such as workbenches, brackets, guide rails, etc. Its high strength and good processing performance can meet the requirements of mechanical manufacturing


Can be used for indoor and outdoor decoration, such as stair handrails, railings, screens, etc., to play a decorative and protective role

304 stainless steel angle stock size table

Drawing

Equal angle(Axt)
Size(mm) Theoretical weight
(kg/m)		 Size(mm) Theoretical weight
(kg/m)		 Size(mm) Theoretical weight
(kg/m)
25x3 1.124 75x7 7.976 110x14 22.809
25x4 1.459 75x8 9.03 125x8 15.504
30x3 1.373 75x10 11.089 125x10 19.133
30x4 1.786 80x6 7.376 125x12 22.696
40x3 1.852 80x7 8.525 125x14 26.193
40x4 2.422 80x8 9.658 140x10 21.488
40x5 2.976 80x10 11.874 140x12 25.522
50x4 3.059 90x6 8.35 140x14 29.49
50x5 3.77 90x7 9.656 140x16 35.393
50x6 4.465 90x8 10.946 160x10 24.729
60x5 4.52 90x10 13.476 160x12 29.391
60x6 5.42 90x12 15.94 160x14 33.987
63x5 4.822 100x6 9.366 160x16 38.518
63x6 5.721 100x7 10.83 180x12 33.159
63x8 7.469 100x8 12.276 180x14 38.383
63x10 9.151 100x10 15.12 180x16 43.542
70x5 5.397 100x12 20.611 180x185 48.634
70x6 6.406 100x16 23.257 200x14 42.894
70x7 7.398 110x7 11.928 200x16 48.68
70x8 8.373 110x8 13.532 200x18 54.401
75x5 5.818 110x10 16.69 200x20 60.056

Chemical composition table of stainless steel angle

Grade Chemical Composition (%)
C Si Mn P S Ni Cr Mo
201 ≤0.15 ≤1.00 5.5~7.5 ≤0.060 ≤0.030 3.50~5.50 16.00~18.00
301 ≤0.15 ≤1.00 ≤2.00 ≤0.045 ≤0.030 6.00~8.00 16.00~18.00
302 ≤0.15 ≤1.00 ≤2.00 ≤0.045 ≤0.030 8.00~10.00 17.00~19.00
304 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.030 8.00~10.50 18.00~20.00 -
304L ≤0.030 ≤1.00 ≤2.00 ≤0.045 ≤0.030 9.00~13.50 18.00~20.00 -
316 ≤0.045 ≤1.00 ≤2.00 ≤0.045 ≤0.030 10.00~14.00 10.00~18.00 2.00~3.00
316L ≤0.030 ≤1.00 ≤2.00 ≤0.045 ≤0.030 12.00~15.00 16.00~18.00 2.00~3.00

50x50x5 304 Angle Steel For Structural Brackets

50x50x5 304 Angle Steel For Structural Brackets

Manufacturing capacity

EDEST STEEL have more than ten years stainless steel products exporting experience, with full range of product lines, including stainless steel bars, profiles, pipes and tubes, stainless steel strips and sheets etc. We have rofessional sales and service teams with our own processing center, enough inventory to make sure fast delivery, products can also be customized. We're aiming to provide customer a One-stop service.

Our commitment

our price may not be the lowest, but we adhere to the "quality first, service first" Our price is reasonable, we will be your most satisfied supplier in China

If you have any questions, please feel free to contact us! We are committed to providing you with the best products at the most reasonable prices, always providing our best service.
