Wireless 1D Handheld Barcode Scanner Reader With USB High Scan Speed
Wireless 1D Handheld Barcode Scanner Reader With USB High Scan Speed
Wireless 1D Handheld Barcode Scanner Reader With USB High Scan Speed
Wireless 1D Handheld Barcode Scanner Reader With USB High Scan Speed
Wireless 1D Handheld Barcode Scanner Reader With USB High Scan Speed
Wireless 1D Handheld Barcode Scanner Reader With USB High Scan Speed
Wireless 1D Handheld Barcode Scanner Reader With USB High Scan Speed
Wireless 1D Handheld Barcode Scanner Reader With USB High Scan Speed
Wireless 1D Handheld Barcode Scanner Reader With USB High Scan Speed
Wireless 1D Handheld Barcode Scanner Reader With USB High Scan Speed
Specifications
Brand Name :
Effon
Model Number :
PTH2
Certification :
CE, ROSH, FCC, IP65 Ect
Place of Origin :
China
MOQ :
4000 pcs
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
70000pcs/ month
Delivery Time :
1 day
Packaging Details :
one piece in one box
Product name :
2D Scanner
Model name :
PTH2-U
Dimensions :
Length:67mm, Width: 90mm, Height:160mm
Weight :
168grams
Electrical :
Power: DC5V Typical: 180mA DC5V
Working mode :
USB mode
Scan mode :
Trigger mode
Ambient illumination :
0～100,000lux(natural light)
Communication :
USB
OS :
IOS, Android, Windows, Mac
Description

2D Handheld Barcode Scanner

Product Features

1. Strong reading performance, quickly read the main code and two-dimensional code on paper, computer or mobile phone screen;

2. Quickly read payment codes, electronic rolls, coupons, etc. on the screen of mobile devices, which can be used for online payment;

3. Support multiple communication methods such as USB, virtual serial port;

4. Applicable to various lighting environments (including completely dark), High temperature and humidity, and various harsh and complex working environments, such as: shock, vibration, and strong exposure;

5. Compatible with Windows, Android and Linux systems.

Product name 2D Scanner
Model name PTH2-U
Dimensions

Length:67mm, Width: 90mm, Height:160mm
Weight 168grams
Electrical Power: DC5V Typical: 180mA DC5V
Working mode USB mode
Scan mode Trigger mode
Ambient illumination 0～100,000lux(natural light)

Scanner performance

Sensor Type: 640 (horizontal) × 480 (vertical) pixels

Light: white LED

red LED

Scanner Angle: ±65°,±65°,±360°(skew, pitch, Roll)

Field of view: Horizontal: 36° , Vertical: 28°

Contrast: ≥20%
Barcode Type 1D Codabar,Code39,code32 Pharmaceutical(PARAF), Interleaved 2 of 5,NEC 2 of 5,Code93, Straight 2 of 5 Industial, Straight 2 of 5 IATA, Matrix 2 of 5, Code 11,Code 128,GS1-128,UPC-A,UPC-E,UCC Coupon Extended Code,EAN/JAN-8, EAN/JAN-13,MS,GSI DataBar Omnidirectional,GSI DataBar Limited,GSI DataBar Expanded,China Post (Hong Kong 2 of 5),Korea Post.
2D CodeblockA,CodeblockF,PDF417,MicroPDF417, GS1 Composite Codes,TL39, QR Code, Data Matrix,MaxiCode,Aztec,HANXIN.

Decoding depth &

Max. Resolution

(1 mil = 0.0254 mm)

 Code 39 30mm -90mm (5mil);
Code 39 40mm -195mm (13mil);
QR Code 30mm -170mm (15mil).
QR Code (Screen) 100mm -500mm (15mil).
Communication USB
OS IOS, Android, Windows, Mac
Certificate

CE, Rohs, FCC, EN60950, IEC60825, EMC.

Utility Model Patent No.: ZL201420211350.8
Laser safety IEC60825-1-2007, Class 1
Temperature

Operating: -20°C to +60°C ;

Storage: -30°C to +70°C
Humidity 5% to 95% (non-condensing)
