PW05 SS 0.5mm Woven Fiberglass Cloth With 314 SS Wire Inserts With PU Coating 0.5mm For Fire Blanket Smoke Curtains
PW05 SS 0.5mm Woven Fiberglass Cloth With 314 SS Wire Inserts With PU Coating 0.5mm For Fire Blanket Smoke Curtains
PW05 SS 0.5mm Woven Fiberglass Cloth With 314 SS Wire Inserts With PU Coating 0.5mm For Fire Blanket Smoke Curtains
PW05 SS 0.5mm Woven Fiberglass Cloth With 314 SS Wire Inserts With PU Coating 0.5mm For Fire Blanket Smoke Curtains
PW05 SS 0.5mm Woven Fiberglass Cloth With 314 SS Wire Inserts With PU Coating 0.5mm For Fire Blanket Smoke Curtains
PW05 SS 0.5mm Woven Fiberglass Cloth With 314 SS Wire Inserts With PU Coating 0.5mm For Fire Blanket Smoke Curtains
Specifications
Brand Name :
Shenghe
Model Number :
PW05 SS 40 gsm PU Coating
Certification :
ISO 9001
Place of Origin :
China
MOQ :
50 Meters
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
1000 meters per day
Delivery Time :
This silicone fabric is cut to order and is not returnable. The high temperature material typically ships out in 1-5 business days.
Packaging Details :
Woven Bag
Product Name :
Reinforced Steel Wire Fiberglass Cloth
Width :
1000 to 2000mm
Yarn Type :
E-glass Fiberglass Fabric with 314 Stainless Steel
Weave Structure :
Plain Weave
Application :
Welding Blanket, Fire Curtain
Satinless Type :
314 Stainless Steel Wire
Standing temperature :
-70-600Degree
Good Features :
Fireproof
Description

PW05 SS 0.5mm Woven Fiberglass Cloth With 314 SS Wire Inserts With PU Coating 0.5mm For Fire Blanket Smoke Curtains

Product Description

This is a kind of 0.5mm thickness thin S.S wire reinforced fiberglass fabric with a formulated polyurethane aluminum polymer which provides a heat reflecting surface as well as other properties for the manufacturer of smoke curtain, heat shield and other types of fire control systems.

Why we used 316/V4A stainless instead of 304 wire?

Type 304 stainless steel is the most common stainless steel formulation used in industrial and consumer applications. Alloyed with chromium and nickel, 304 is resistant to many corrosion attacks.

316 stainless steel is similar in chemical composition to 304 but also contains molybdenum. This addition makes it more resistant to corrosion.

In other words, 316 steel wire has higher tensile strength than 304, can provide higher temperature resistance, and can improve service life in harsh environments

Product Features

Nominal Width: 100/120cm

Nominal Weight: 520gsm

Nominal Thickness: 0.5mm

Base Cloth Temperature Resistance 600oC

Content: Warp: 100% Fiberglass Yarns

Fill: Stainless Steel Wire (314) Plied With Fiberglass Yarns

Weave can be one-directional (stainless is only inserted in warp yarn) or two-directional (stainless is inserted in both warp yarn and weft yarn)

Count Warp: 16

Fill: 9

Material should be tested for its suitability in any application. Users should also familiarize themselves with the SDS before handling.

Application

Fire and smoke curtains

Reusable heat insulation covers

Waterproof

800 degress heat resistance

Fire retardant

High Strength

Durable

Technique Data Sheet for Stainless Steel Wire Fiberglass Cloth

Items Technical Requirement
Width 100cm
Cloth Thickness 0.55±0.05 mm
Cloth Weight 520g/m2
Treatment PU 1 Side
Color for Coating Silver Grey
Warp Yarn 150 Tex + Stainless Wire
Weft Yarn 150 Tex + Stainless Wire
Warp and Weft Density 16*9 Ends/cm
Warp Tensile Strength [25*200mm] 3400N/5cm
Weft Tensile Strength [25*200mm] 3000N/5cm
Temperature Resistance 600oC

Much More Related Stainless Steel FIberglass Cloth

Product Type Thickness mm Weight g/m2 Weave
PW05 SS 0.5 455 Plain
666 SS 0.6 630 8H Satin
666 SS 0.6 630 8H Satin
M860W SS 0.8 820 Dougle Weft Yarn
M860 SS 0.75 820 8H Satin
M860C SS 0.8 820 Close To Satin
M30 SS 1.2 1050 Plain
Other thicknesses can be customized upon request

More Detail Images

PW05 SS 0.5mm Woven Fiberglass Cloth With 314 SS Wire Inserts With PU Coating 0.5mm For Fire Blanket Smoke Curtains

PW05 SS 0.5mm Woven Fiberglass Cloth With 314 SS Wire Inserts With PU Coating 0.5mm For Fire Blanket Smoke Curtains

More Related Reinforced Fiberglass Fabric With Steel Wire Fiberglass Cloth

Packing

PW05 SS 0.5mm Woven Fiberglass Cloth With 314 SS Wire Inserts With PU Coating 0.5mm For Fire Blanket Smoke Curtains

PW05 SS 0.5mm Woven Fiberglass Cloth With 314 SS Wire Inserts With PU Coating 0.5mm For Fire Blanket Smoke Curtains

Why Choose Us?

With a complete industrial chain, we can totally control the product quality and delivery time.

High quality products

ISO9001 2015 Certification

100% Testing before shipment, All products must pass the factory test

Different Sized of materials can be provided according to customer needs

RFQ

1. Are you a factory or trading company?

A: We are a factory.

2. How to get free samples?

A: You can contact our sales staff. We can send you some samples for free. But we do not pay for shipping.

3. Are your products certified?

A: Yes, we have a third party fire inspection report

4. How to package your product?

A: We pack the product in a carton or PVC bag. We can also pack according to customers' requirements.

5. Are you a manufacturer?

A: Yes, we are a Chinese manufacturer. We have advanced looms to provide basic cloth

6. Q:Do you have other production?

A:Certainly,we still have E-glass fiberglass fabric, industry fiberglass cloth, High silica cloth, silicone, polyurethane, graphite, vercimiute, EPDM, fluoro,aluminium coated fiberglass cloth. We are looking forward to your enquiry.
