Silicone Coated Fiberglass High Temp Wire Sleeve Exhaust Insulation Heat Shield
Silicone Coated Fiberglass High Temp Wire Sleeve Exhaust Insulation Heat Shield
Silicone Coated Fiberglass High Temp Wire Sleeve Exhaust Insulation Heat Shield
Silicone Coated Fiberglass High Temp Wire Sleeve Exhaust Insulation Heat Shield
Silicone Coated Fiberglass High Temp Wire Sleeve Exhaust Insulation Heat Shield
Silicone Coated Fiberglass High Temp Wire Sleeve Exhaust Insulation Heat Shield
Specifications
Brand Name :
Shenghe
Model Number :
Silicone Coated Fiberglass Sleeving
Certification :
ROSH SGS
Place of Origin :
China
MOQ :
100 Meters
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
50000Meters/Day
Delivery Time :
5-7 Work days
Packaging Details :
Roll
Product Name :
Heat Resistant Hose and Cable Protective Pyrojacket Fire Sleeve
Size :
6-150mm
Performance :
Fire-proof and High Temperature
Aging Test :
260ºC,6 hrs without crackle
Continuous Operating Temperature :
-10ºC+200ºC
Name :
Hose fire sleeve
Application :
Used to Protect Hoses, Wires And Cables
Flammability :
Impede heat radiation of flame
Description

Silicone coated fiberglass high temp wire exhaust insulation heat shield silicone fire sleeve

Description for High-Temperature Silicone Rubber Fiberglass Sleeving

Economic Silicone Rubber Fiberglass Braided Fire Sleeve is constructed from a high bulk glass fiber braided sleeve. Excellent modulus of elasticity makes it an excellent choice for bundling hoses, tubes, and cables in a variety of hostile environments. Protect your personnel and cut your energy loss economic Grade Fire Sleeve is an insulation property that provides personnel with effective protection against burns from hot hoses and flexible steam lines while reducing heat energy losses. Always wear safety glasses, dust mask, gloves, and long sleeves are recommended when handling this product

Inner diameter 10mm-115mm
Color Red, black, other colors can be made according to customer's need, nylon fastening optional color: white or black
Work temperature Can used continuously at - 75 ° C to 260 ° C, short moment resistance can be up to 1650 ° C
Nominal voltage 7kv--25 kv.
Product properties Fire prevention, flame retardant, heat insulation, insulation, anti-aging, prevent splas

Operation Temperature

Continuous Operating Temperature: -65 ° C - 260 ° C

15-20 minutes: 1090 ° C

15-30 seconds: 1650 ° C

Technique Data

Description: Texturized fiberglass sleeve with silicone coating
Contents: 100% glass fiber and silicone rubber
Yarn type: 9 um
Internal Diameter : 30mm
Thermal Conductivity 0.035(w/(m.k)
Continuous Temp resistance: No more than 550 0C
Freeze temp: -50 0C
Loss on Ignition ≦3.52%
Chemical composition
SiO2 Al2O3 CaO MgO R2O Fe2O3
67.3±0.5 % 6.4±0.4% 9.6±0.3% 4.5±0.3 % 11.8~16.1% ≤0.4

Features:

1, Fireproof, flame retardant, heat insulation.
2, Heat prevention, insulation, anti-aging
3, Withstand melting metal splash
4, Withstand strong heat source and flame.
5, Anti-acid and anti-alkali

Application:

It also provides a high degree of insulation value, protecting hot, cold or cryogenic lines, pipes and tubing from heat or cold loss, providing energy savings and abrasion resistance

Silicone Coated Fiberglass High Temp Wire Sleeve Exhaust Insulation Heat ShieldSilicone Coated Fiberglass High Temp Wire Sleeve Exhaust Insulation Heat Shield

Detail Images

Silicone Coated Fiberglass High Temp Wire Sleeve Exhaust Insulation Heat Shield

The Other Types Recommended:

Dia (mm) Internal Dia (mm) Length (m) Thickness(mm)
Silicone Glass Yarn
1 6 6.5 20 0.6 1.0
2 8 8.5 20 0.8 1.0
3 10 10.5 20 0.8 1.0
4 12 12.5 20 0.8 1.2
5 15 15.5 20 0.9 1.2
6 20 20.5 20 0.9 1.4
7 22 22.5 20 0.9 1.4
8 25 25.5 20 1 1.6
9 30 30.5 20 1.1 1.8
10 32 32.5 20 1.2 1.8
11 35 35.5 20 1.1 2
12 40 40.5 20 1.2 2.1
13 45 45.5 20 1.2 2.2
14 50 51 20 1.2 2.3
15 55 56 20 1.3 2.4
16 60 61 20 1.3 2.5
17 65 66 20 1.3 2.6
18 70 71 20 1.4 2.7
