32Inch AUO Digital signage lcd display screens P320HVN02.0 1920(RGB)×1080 (FHD) 69PPI 500cd/m² 51PIN 12V

P320HVN02.0 is a 32.0" diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.0G (9.8 m/s²). It's general features are summarized by einklcd in the following: sRGB, Landscape / Portrait, WLED Backlight, Life ≥ 50K hours, With LED Driver, Matte . Based on its features, einklcd recommend that this model be applied to Digital Signage etc. According to the information stored in einklcd this model mass production on Q4, 2014, Now this model is in production. We inputted this model's specification on Apr 30 2014 for the first time, and the latest update on Sep 27 2019. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail of P320HVN02.0. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

• ManufacturerAUO
• Model NameP320HVN02.0

• Screen Size32.0 inch
• Screen TypeLCM, a-Si TFT-LCD

• Pixel Number1920(RGB)×1080 (FHD) 69PPI
• ArrangementRGB Vertical Stripe

• Active Area(mm)698.4 × 392.85 (H×V)
• Outline(mm)719.2 × 413.7 × 24.8 (H×V×D)

• Bezel Area(mm)703.4 × 397.9 (H×V)
• TreatmentAntiglare (Haze 2%), Hard coating (3H)

• Luminance500 cd/m² (Typ.)
• Contrast Ratio3000 : 1 (Typ.) (TM)

• Viewing Angle89/89/89/89 (Typ.)(CR≥10)
• Response8 (Typ.)(G to G) ms

• Good View atSymmetry
• Work ModeAMVA3, Normally Black, Transmissive

• Color Depth16.7M 99% sRGB
• BacklightWLED , 50K hours , With LED Driver

• Mass4.59Kgs (Typ.)
• Used for

• Refresh Rate60Hz
• TouchscreenWithout

• Signal Type
• LVDS (2 ch, 8-bit) , 51 pins Connector

• Voltage Supply
• 12.0V (Typ.)

• Max. Ratings
• Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
