1024*768 Pixels Industrial LCD Display Glass Oled 600cd/m2 Brightness G121XCE-L01
1024*768 Pixels Industrial LCD Display Glass Oled 600cd/m2 Brightness G121XCE-L01
1024*768 Pixels Industrial LCD Display Glass Oled 600cd/m2 Brightness G121XCE-L01
1024*768 Pixels Industrial LCD Display Glass Oled 600cd/m2 Brightness G121XCE-L01
1024*768 Pixels Industrial LCD Display Glass Oled 600cd/m2 Brightness G121XCE-L01
1024*768 Pixels Industrial LCD Display Glass Oled 600cd/m2 Brightness G121XCE-L01
Specifications
Brand Name :
INNOLUX
Model Number :
G121XCE-L01
Certification :
Rohs,CE,FCC
Place of Origin :
KOREA
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
T/T,W, Western Union, MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
material :
glass oled
color :
16.7M colors
model :
WLED
style :
wide screen high resolution 1024*768
brightness :
600cd
connector :
20pin
contrast ratio :
1000:1
working life :
50K hours
Description
  • Brand Innolux Model G121XCE-L01
    Diagonal Size 12.1 inch Type a-Si TFT-LCD , LCM
    Pixel Format 1024(RGB)×768 [XGA] Configuration RGB Vertical Stripe
    Active Area 245.76(H)×184.32(V) mm Outline Dim. 260.5(H)×204(V) ×8.9(D) mm
    Bezel Area 249.0(H)×187.5(V) mm Treatment Antiglare, Hard coating (3H)
    Luminance 600 cd/m² (Typ.) Contrast Ratio 1000:1 (Typ.) (TM)
    View Direction Symmetry Response Time 13/12 (Typ.)(Tr/Td)
    Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Operating Mode AAS, Normally Black, Transmissive
    Support Color 262K/16.2M 72% (CIE1931) Light Source WLED , 50K hours , With LED Driver
    Weight 490/510g (Typ./Max.) Designed For
    Frame Rate 60Hz Touch Panel Without
    Interface Type 20 pins LVDS (1 ch, 6/8-bit) , Connector
    Power Supply 3.3V (Typ.)
    Environment Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C

    1024*768 Pixels Industrial LCD Display Glass Oled 600cd/m2 Brightness G121XCE-L011024*768 Pixels Industrial LCD Display Glass Oled 600cd/m2 Brightness G121XCE-L01

  • Innolux Corporation (hereafter called Innolux) G121XCE-L01 is a 12.1 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -30 ~ 85°C , a storage temperature range of -40 ~ 90°C . It's general features are summarized by Einklcd in the following: High Color Gamut, Antiglare Surface, 6/8 bit Selectable, Wide Viewing Angle, Landscape type, Wide Temperature, Hight Brightness, White LED Backlight, Lamp life ≥ 50K hours, Normal Signal Interface Position, U/D,L/R Reverse . Based on its features, Einklcd recommend that this model be applied to Industrial etc. According to the information stored in Einklcd this model mass production on Q1, 2018, Now this model is in production. We inputted this model's specification on Dec 25 2017 for the first time. If you want to embed G121XCE-L01 LCM in your future product, einklcd strongly recommend that you should contact with Innolux or it's distributor to learn lateast production and specification detail. The G121XCE-L01 production status marked on Einklcd.com is for reference only and should not be used as the basis for the user's decision making

It's 500cd/m2 lcd MODEL for industrial lcd ,computer,all-in-one computer,desktop,laptop lcd.

All our LCD LED screen monitor module panel products will be full test one by one before sending .
