LG 24 Inch Industrial LCD Display LM240WU9-SLA1 1920*1200 Pixels 350cd/m2 Brightness
LG 24 Inch Industrial LCD Display LM240WU9-SLA1 1920*1200 Pixels 350cd/m2 Brightness
LG 24 Inch Industrial LCD Display LM240WU9-SLA1 1920*1200 Pixels 350cd/m2 Brightness
LG 24 Inch Industrial LCD Display LM240WU9-SLA1 1920*1200 Pixels 350cd/m2 Brightness
LG 24 Inch Industrial LCD Display LM240WU9-SLA1 1920*1200 Pixels 350cd/m2 Brightness
LG 24 Inch Industrial LCD Display LM240WU9-SLA1 1920*1200 Pixels 350cd/m2 Brightness
LG 24 Inch Industrial LCD Display LM240WU9-SLA1 1920*1200 Pixels 350cd/m2 Brightness
LG 24 Inch Industrial LCD Display LM240WU9-SLA1 1920*1200 Pixels 350cd/m2 Brightness
Specifications
Brand Name :
LG
Model Number :
LM240WU9-SLA1
Certification :
Rohs,CE,FCC
Place of Origin :
Korea
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
T/T,W, Western Union, MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
material :
glass oled
color :
1.07b colors
model :
WLED
style :
wide screen high resolution 1920*1200
brightness :
350cd
connector :
51PIN
contrast ratio :
1000:1
working life :
30K hours
Description
Manufacturer LG Display Model Name LM240WU9-SLA1
Screen Size 24.0 inch Screen Type LCM , a-Si TFT-LCD
Pixel Number 1920(RGB)×1200 (WUXGA) Arrangement RGB Vertical Stripe
Active Area(mm) 518.4 × 324 (H×V) Outline(mm) 546.4 × 352 × 16 (H×V×D)
Bezel Area(mm) 522.4 × 328.0 (H×V) Treatment Antiglare, Hard coating (3H)
Luminance 350 cd/m² (Typ.) Contrast Ratio 1000 : 1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Response 6 (Typ.)(G to G) ms
Good View at Symmetry Work Mode AH-IPS, Normally Black, Transmissive
Color Depth 1.07B 99% (Adobe) Backlight GB-r LED , 30K hours , No Driver
Mass 2.45/2.58Kgs (Typ./Max.) Used for
Refresh Rate 60Hz Touchscreen Without
Signal Type LVDS (2 ch, 10-bit) , Connector , 51 pins
Voltage Supply 12.0V (Typ.)
Max. Ratings Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C

LM240WU9-SLA1 (Alias: LM240WU9 (SL)(A1)) is a 24.0" diagonal a-Si TFT-LCD display panel product from LG Display Co., Ltd. (hereafter called LG Display), with an integral GB-r LED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: Adobe RGB, Antiglare Surface, 10 bit, Wide Viewing Angle, Landscape type, Wide Aspect Ratio, Normal Signal Interface Position , Adobe RGB. Based on its features, einklcd recommend that this model be applied to Desktop Monitor, Industrial, Medical Imaging etc. According to the information stored in einklcd this model mass production on Q4, 2012 and last shippment on Q2, 2016, Now this model is discontinued. We inputted this model's specification on Apr 8 2013 for the first time, and the latest update on Aug 31 2018. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with LG Display or it's agent to learn lateast production and specification detail of LM240WU9-SLA1. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

LG 24 Inch Industrial LCD Display LM240WU9-SLA1 1920*1200 Pixels 350cd/m2 BrightnessLG 24 Inch Industrial LCD Display LM240WU9-SLA1 1920*1200 Pixels 350cd/m2 BrightnessLG 24 Inch Industrial LCD Display LM240WU9-SLA1 1920*1200 Pixels 350cd/m2 BrightnessLG 24 Inch Industrial LCD Display LM240WU9-SLA1 1920*1200 Pixels 350cd/m2 Brightness

All our LCD LED screen monitor module panel products will be full test one by one before sending .
