Brand

Innolux

Model

G260JJE-L07

Diagonal Size

25.5 inch

Type

a-Si TFT-LCD, LCM

Pixel Format

1920(RGB)×1200 [WUXGA]

Configuration

RGB Vertical Stripe

Active Area

550.08(H)×343.8(V) mm

Outline Dim.

582(H)×375.6(V) ×30.6(D) mm

Bezel Area

554.1(H)×347.8(V) mm

Treatment

Antiglare, Hard coating (3H)

Luminance

350 cd/m² (Typ.)

Contrast Ratio

1500:1 (Typ.) (TM)

View Direction

Symmetry

Response Time

15/5 (Typ.)(Tr/Td)

Viewing Angle

88/88/88/88 (Typ.)(CR≥10)

Operating Mode

Super MVA, Normally Black, Transmissive

Support Color

16.7M 72% (CIE1931)

Light Source

WLED , 50K hours , With LED Driver

Weight

3.65/3.85Kgs (Typ./Max.)

Designed For

Frame Rate

60Hz

Touch Panel

Without

Interface Type

30 pins LVDS (2 ch, 8-bit) , Connector

Power Supply

5.0V (Typ.)

Environment

Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

The G260JJE-L07 is a 25.5 inch diagonal a-Si TFT-LCD display panel product from Innolux Corporation (hereafter called Innolux), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: High Color Gamut, Antiglare Surface, Wide Viewing Angle, Landscape type, White LED Backlight, Lamp life ≥ 50K hours, Wide Aspect Ratio, Normal Signal Interface Position . Based on its features, einklcd recommend that this model be applied to Industrial etc. According to the information stored in einklcd this model mass production on Q4, 2013, Now this model is in production. We inputted this model's specification on Aug 14 2013 for the first time, and the latest update on Jun 14 2019. If you want to embed G260JJE-L07 LCM in your future product, Einklcd strongly recommend that you should contact with Innolux or it's agent to learn lateast production and specification detail. The G260JJE-L07 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
