1920*1080 Touch Screen Desktop Monitor Innolux 21.5 TV M215HJJ-P02 30 Pin Connector
1920*1080 Touch Screen Desktop Monitor Innolux 21.5 TV M215HJJ-P02 30 Pin Connector
1920*1080 Touch Screen Desktop Monitor Innolux 21.5 TV M215HJJ-P02 30 Pin Connector
1920*1080 Touch Screen Desktop Monitor Innolux 21.5 TV M215HJJ-P02 30 Pin Connector
1920*1080 Touch Screen Desktop Monitor Innolux 21.5 TV M215HJJ-P02 30 Pin Connector
1920*1080 Touch Screen Desktop Monitor Innolux 21.5 TV M215HJJ-P02 30 Pin Connector
Specifications
Brand Name :
Innolux
Model Number :
M215HJJ-P02
Certification :
Rohs,CE,FCC
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
T/T,W, Western Union, MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
material :
glass oled
color :
16.7m colors
model :
WLED
style :
wide screen high resolution 1920*1080
brightness :
400cd
connector :
30PIN
contrast ratio :
3000:1
working time :
30k hours
Description
Panel Brand
Panel Size
Resolution
Display Area
Outline Size
Brightness
Viewing Angle
Best View on
Glass Depth
Display Colors
Frequency
Weight
Innolux
21.5"
1920(RGB)×1080 , FHD
476.064(W)×267.786(H) mm
487.664(W)×279.286(H) ×1.288(D) mm
0 cd/m²
89/89/89/89 (Typ.)(CR≥20)
Symmetry
0.50+0.50 mm
16.7M 72% (CIE1931)
60Hz
400g (Typ.)
Panel Model
Panel Type
Pixel Format
Bezel Opening
Surface
Contrast Ratio
Display Mode
Response Time
Transmissivity
Lamp Type
Touch Screen
Application
M215HJJ-P02
a-Si TFT-LCD , CELL
RGB Vertical Stripe
-
Antiglare (Haze 25%), Hard coating (3H)
3000:1 (Typ.) (TM)
MVA, Normally Black, Transmissive
20/5 (Typ.)(Tr/Td)
4.46% (Typ.)(with Polarizer)
No B/L
Without
Signal Interface LVDS (2 ch, 8-bit) , 30 pins , Connector
Input Voltage 5.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C

1920*1080 Touch Screen Desktop Monitor Innolux 21.51920*1080 Touch Screen Desktop Monitor Innolux 21.5

M215HJJ-P02 is a 21.5" diagonal a-Si TFT-LCD display panel product from Innolux Corporation (hereafter called Innolux), without backlight, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by EINKLCD in the following: High Color Gamut, Antiglare Surface, Wide Viewing Angle, Landscape type, Wide Aspect Ratio . Based on its features, Einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q4, 2014, Now this model is in production. We inputted this model's specification on Nov 10 2014 for the first time, and the latest update on Sep 7 2017. If you want to embed the CELL in your future product, einklcd strongly recommend that you should contact with Innolux or it's agent to learn lateast production and specification detail of M215HJJ-P02. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
