AUO 31.5 LCD Touch Screen Monitor T320HVN05.6 1920*1080 51Pin For Desktop Monitor TV Panel
AUO 31.5 LCD Touch Screen Monitor T320HVN05.6 1920*1080 51Pin For Desktop Monitor TV Panel
Specifications
Brand Name :
auo
Model Number :
T320HVN05.6
Certification :
Rohs,CE,FCC
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
T/T,W, Western Union, MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
material :
glass oled
color :
16.7m colors
model :
WLED
style :
wide screen high resolution 1920*1080
brightness :
400cd
connector :
50PIN
contrast ratio :
4000:1
working time :
30k hours
Description

AUO 31.5" LCD Touch Screen Monitor T320HVN05.6 51Pin 1920*1080 For Desktop Monitor TV Panel

Panel Brand AUO Panel Model T320HVN05.6 CELL
Panel Size 31.5" Panel Type a-Si TFT-LCD , CELL
Resolution 1920(RGB)×1080 , FHD Pixel Format RGB Vertical Stripe
Display Area 698.4(W)×392.85(H) mm Bezel Opening -
Outline Size 708.4(W)×405.4(H) ×1.4(D) mm Surface Antiglare (Haze 2%), Hard coating (3H)
Brightness 0 cd/m² Contrast Ratio 4000:1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Display Mode AMVA3, Normally Black, Transmissive
Best View on Symmetry Response Time 6.5 (Typ.)(G to G)
Glass Depth 0.50+0.50 mm Transmissivity 6.5% (Typ.)(with Polarizer)
Display Colors 16.7M Lamp Type No B/L
Frequency 60Hz Touch Screen Without
Panel Weight 875g (Typ.) Application
Signal Interface LVDS (2 ch, 8-bit) , 51 pins , Connector
Input Voltage 12.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C

AU Optronics Corp. (hereafter called AUO) T320HVN05.6 CELL is a 32.0 inch diagonal a-Si TFT-LCD display panel product, without backlight, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: Reverse I/F, Matte . Based on its features, einklcd recommend that this model be applied to TV Sets etc. According to the information stored in einklcd this model mass production on Q4, 2014, Now this model is in production. We inputted this model's specification on Oct 30 2014 for the first time, and the latest update on Jul 29 2019. If you want to embed T320HVN05.6 CELL CELL in your future product, einklcd strongly recommend that you should contact with AUO or it's distributor to learn lateast production and specification detail. The T320HVN05.6 CELL production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

AUO 31.5

All this lcd product are brand new with original package!
