Specifications
Brand Name :
BOE
Model Number :
DV480FBM-N00
Certification :
Rohs,CE,FCC
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
T/T,W, Western Union, MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
material :
glass led
color :
16.7M
model :
WLED,LCD
style :
wide screen high resolution 1920*1080pixels
resolution :
3840*720
brightness :
1000CCD/M2
connector :
51P
working life :
50k hours
Description

BOE bar Screen module 48" DV480FBM-N00 high brightness 1000CCD/M2 HD 3840*720ixels for advisement player 16.7M colors

Manufacturer BOE Model Name DV480FBM-N00
Screen Size 48 inch Screen Type LCM , a-Si TFT-LCD
Pixel Number 3840(RGB)×720 Arrangement RGB Vertical Stripe
Active Area(mm) 1194.05 × 223.884 (H×V) Outline(mm) 1217.9 × 248.2 × 30.58 (H×V×D)
Bezel Area(mm) - Treatment Antiglare (Haze 1%), Hard coating (3H)
Luminance 1000 cd/m² (Typ.) Contrast Ratio 1000 : 1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Response 16 (Typ.)(Tr+Td) ms
Good View at Symmetry Work Mode ADS, Normally Black, Transmissive
Color Depth 16.7M 72% (CIE1931) Backlight WLED , 50K hours , With LED Driver
Mass 3.7Kgs (Typ.) Used for
Refresh Rate 60Hz Touchscreen Without
Signal Type V-by-One 8 lane , Connector , 51 pins
Voltage Supply 12.0V (Typ.)
Max. Ratings Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C

Bar Type Large Screen Monitor , High Brightness HD 16.7M Colors Led Display Screen Bar Type Large Screen Monitor , High Brightness HD 16.7M Colors Led Display Screen Bar Type Large Screen Monitor , High Brightness HD 16.7M Colors Led Display Screen Bar Type Large Screen Monitor , High Brightness HD 16.7M Colors Led Display Screen Bar Type Large Screen Monitor , High Brightness HD 16.7M Colors Led Display Screen Bar Type Large Screen Monitor , High Brightness HD 16.7M Colors Led Display Screen

All our LCD LED screen monitor module panel products will be full test one by one before sending .
