Specifications
Brand Name :
CHIMEI innolux
Model Number :
S650DJ4-KS5
Certification :
Rohs,CE,FCC
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
T/T,W, Western Union, MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
material :
glass oled
color :
black or silver
model :
WLED
style :
wide screen high resolution 3140*2160
Description

  • Innolux 65 Inch LED TV module S650DJ4-KS5 Screen Display 3140*2160 51P

    Manufacturer

    Innolux

    Model Name

    S650DJ4-KS5 Rev.T4

    Screen Size

    65 inch

    Screen Type

    CELL , a-Si TFT-LCD

    Pixel Number

    3840(RGB)×2160 (UHD)

    Arrangement

    RGB Vertical Stripe

    Active Area(mm)

    1428.48 × 803.52 (H×V)

    Outline(mm)

    1106.84 × 628.01 × 1.32 (H×V×D)

    Bezel Area(mm)

    -

    Treatment

    Antiglare (Haze 1%), Hard coating (3H)

    Luminance

    0 cd/m²

    Contrast Ratio

    5000 : 1 (Typ.) (TM)

    Viewing Angle

    89/89/89/89 (Typ.)(CR≥10)

    Response

    9.5 (Typ.)(G to G) ms

    Good View at

    Symmetry

    Work Mode

    Super MVA, Normally Black, Transmissive

    Glass Thickness

    -

    Transmissivity

    5.4% (Typ.)(with Polarizer)

    Color Depth

    1.07B

    Backlight

    No B/L , 30K hours

    Mass

    2.06Kgs (Typ.)

    Used for

    Innolux 65 Inch LED LCD TV Panel 3140 * 2160 Pixels 51P RGB Vertical Stripe Innolux 65 Inch LED LCD TV Panel 3140 * 2160 Pixels 51P RGB Vertical Stripe

    Refresh Rate

    60Hz

    Touchscreen

    Without

    Signal Type

    V-by-One 8 lane , Connector , 51 pins

    Voltage Supply

    12.0V (Typ.)

    Max. Ratings

    Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C

All our LCD LED screen monitor module panel products will be full test one by one before sending .
