TD 114 42-114 Mm Welded Tube Mill Line High Efficient
TD 114 42-114 Mm Welded Tube Mill Line High Efficient
TD 114 42-114 Mm Welded Tube Mill Line High Efficient
TD 114 42-114 Mm Welded Tube Mill Line High Efficient
TD 114 42-114 Mm Welded Tube Mill Line High Efficient
TD 114 42-114 Mm Welded Tube Mill Line High Efficient
TD 114 42-114 Mm Welded Tube Mill Line High Efficient
TD 114 42-114 Mm Welded Tube Mill Line High Efficient
TD 114 42-114 Mm Welded Tube Mill Line High Efficient
TD 114 42-114 Mm Welded Tube Mill Line High Efficient
Specifications
Brand Name :
JUNXI
Model Number :
TD114
Certification :
ce
Place of Origin :
china
Max Pipe Diameter :
42-114MM
Maximum Dhickness :
0.9-6.0mm
Customization :
Comprehensive scheme customization of equipment
Service :
Lifetime maintenance
color :
blue
name :
TD 114 Tube Mill 42-114 mm tube mill line
Description

114 Tube Mill Machine details

The ERW 114 high-frequency straight seam welded pipe production line tube mill machine is designed to produce round pipes with diameters of 42mm-114mm , thicknesses of 0.9mm-6.0mm and square pipes of 30*30-90*90 tubes and 30*60-60*120 rectangular tubes.

Type HF Solid state steel pipe welding production line Line speed ≤90m/min
Round pipe dia Φ42-Φ114 mm Round pipe thickness 0.9 - 6.0mm
Square tube size 30*30-90*90mm Square tube thickness 0.9 - 6.0mm
Rectangular tube 30*60-60*120mm Rectangular tube thickness 0.9 - 6.0mm
Pipe material Carbon steel/Galvanized steel Forming method Round tube to square tube, quick change system

114 Tube Mill Machine Features and Advantages

Tube mill machine rolls quick change system:

Quick roll changes can significantly reduce downtime, thereby increasing production efficiency.

Reduce manual operations,traditional roll replacement usually requires more manual operations, while the quick-change system can realize automated or semi-automatic roll replacement, reducing manual intervention and reducing labor costs.

Enhanced production flexibility, the quick-change system can more quickly adapt to the production needs of pipes of different specifications and materials.

strong and sturdy:

Our high-frequency welded tube mill machines have strong structural design and durability, and can maintain stable operation in long-term, high-intensity production environments.

Worry-free after-sale service:

It can quickly respond to customer needs and ensure continuous production of the pipe machine production line.

Tube mill diagram

We have a professional technical engineer department to provide you with tube mill machine drawings suitable for your factory

TD 114 42-114 Mm Welded Tube Mill Line High EfficientTD 114 42-114 Mm Welded Tube Mill Line High EfficientTD 114 42-114 Mm Welded Tube Mill Line High Efficient
