Junfeng Vehicle water tank truck，large water storage capacity
Junfeng Vehicle water tank truck，large water storage capacity
Specifications
Brand Name :
Dongfeng
Model Number :
JF-LZ1181M3AZBEVT
Place of Origin :
China
MOQ :
2 unit
Price :
FCA (email reply based on different models)
Payment Terms :
T/T
Supply Ability :
less than1000pcs/month (Orders must be made 30 davs in advance if more than 1000)
Delivery Time :
30-45 days
Description
basic parameters LZ1181M3AZBEVT
Driver classification 4x2
curb weight 8300kg
gross weight 18000kg
size 7370x2530x3030
Approach angle/departure angle 16/15
Front overhang/rear overhang 1445/1425
maximum speed 90km/h
wheelbase 5700
cab M3
Battery pack EVE Energy 210kwh (European standard charging port and charging protocol)
electric machinery
(Model/Peak Power)		 TZ342XSSFY02
transmission case 6E95
front axle 5T
Rear axle/speed ratio 153/5.571
Leaf spring 3/4+3
Frame 264(6)
tyre 11R22.5-18PR
Other configurations
"M31RB right-hand drive cab, side-mounted battery pack, liquid-cooled battery pack, dual-gun charging, self-adjusting arm, 264 (6) single-layer frame, 3/4+3 leaf springs, mechanical full-floating cab suspension, manual hydraulic flip, mechanical shock-absorbing driver's seat, electric glass lift, laminated glass, WABCO valve (air handling unit, parking manual valve), WABCO ABS, same-color bumper + fender, electronic cooling fan, electric air compressor, electric steering pump, PTC (electric heating) air conditioning, maintenance-free battery, 24V electrical system, cruise control"
Effective volume 16m³
Tank body shape circular
Tank material 5mm(carbon steel)
Head thickness 6mm(carbon steel)
Number of wave deflectors 3
Thickness of wave deflector 3mm(carbon steel)
welding technology
Robot automatic welding
Visible water storage capacity PVC measuring tube
low water-level alarm not have
Tank body and mouth Automatic control activation
Water addition method Self suction/fire water
supply/tank top
Unpressurized water supply tail

supporting system		 Reinforcement of auxiliary
beams
water pump sprinkler system
water pump HangzhouWeilong
50/110 (export type)
