9A - 95A General Electric Contactor 3P 4P 50 60HZ Changeover
9A - 95A General Electric Contactor 3P 4P 50 60HZ Changeover
9A - 95A General Electric Contactor 3P 4P 50 60HZ Changeover
9A - 95A General Electric Contactor 3P 4P 50 60HZ Changeover
Specifications
Brand Name :
YOKG
Model Number :
SC09
Certification :
CE,TUV,CB
Place of Origin :
China
MOQ :
100PCS
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T
Supply Ability :
100000pcs per Month
Delivery Time :
15days or Depends on ordering QTYS
Packaging Details :
Standard export packing or According to customer's demand
Coil Voltage :
24V, 36V, 48V, 110V, 220V, 230V, 240V, 380V, 415V
Items :
AC Contactor
Application :
auxiliary contact block,timer delay etc.
Current Range :
9A, 12A,18A, 25A, 32A, 40A, 50A, 65A,80A, 95A
Sample :
Available
Poles Number :
3
Description

9A-95A General Electric Contactor 3P 4P 50 60HZ Changeover Contactor

Application:

SC series AC contactor (hereinafter contactor) is suitable for using in the circuits up to the rated voltage 690V AC 50 HZ or 60 HZ , rated current up to 95A, for making, breaking, frequently starting & controlling the AC motor. Combined with the thermal relay, it becomes the electromagnetic starter for protecting the overload circuits.

This series contactor complies with GB 14048, IEC60947-4-1

General:

*The installation altitude less than 2000m.

*The surrounding temperature range: from -5°C ~ +40°C.

*In the non-explosive condition. or without adequate erosion and

destruction of gas and dust conductive area .

*Without rain and snow invade.

* Pollution level 2.

Model and Implication:

9A - 95A General Electric Contactor 3P 4P 50 60HZ Changeover

Main parameters and Technical Performance:

Type SC09
Rated heating current (A) 20
Rated insulation voltage (V) 690
Rated impact withstand voltage (KV) 6
Rated making capacity 10le
Rated breaking capacity 8le
Poles 3
Auxiliary contact NO/NC
Short-time withstand current(A) 10S 72
Rated working current(A) 380V AC-3 9
AC-4 3.5
660V AC-3 6.6
AC-4 1.5
AC-3 capacity of phase 3
squirrel-cage motor (AC-3) KW		 220V 2.2
380V 4
660V 5.5
Operation frequency (times/h) Electrical life AC-3 1200
AC-4 300
Mechanical life 3600
Electrical life (10000/times) AC-3 100
AC-4 20
Mechanical life (10000/times) 1000
Equipped fuse type RT16-20
Rated control supply voltage Us(V) 50/60Hz 12~480
Operation range Pull-in (85%~110%)Us +40℃
Releasing (20%~75%)Us -5℃
Ac coil average power(VA) Start 70
Keeping 8
Power efficiency class class 3
Thermal loss(W) 2~3
Actuation time(ms) Close 12~25
Break 5~20
Main circuit wiring flexible wire without cold
pressing terminal (㎟)		 1 stick 1～4
2 sticks 1～4
flexible wire with cold
pressing terminal (㎟)		 1 stick 1～4
2 sticks 1～2.5
Hard wire (㎟) 1 stick 1~4
2 sticks 1～4
Fastening screw size M3.5
Tightening fastening torque (N.m) 0.8
Control loop wiring flexible wire without cold
pressing terminal (㎟)		 1 stick 1～4
2 sticks 1～4
flexible wire with cold
pressing terminal (㎟)		 1 stick 1～4
2 sticks 1～2.5
Hard wire (㎟) 1 stick 1～4
2 sticks 1～4
Fastening screw size M3.5
Tightening fastening torque (N.m) 0.8

Installation dimension:

9A - 95A General Electric Contactor 3P 4P 50 60HZ Changeover

A max B max C max a b ∅
57 86 95 40 48 4.5

9A - 95A General Electric Contactor 3P 4P 50 60HZ Changeover

9A - 95A General Electric Contactor 3P 4P 50 60HZ Changeover

Why Choose Us:

a. Reply your inquire in 24 working hour.
b. Technical and professional guidance.
c. Best quality and best price.

We maintain excellent products and strive for 100% customer satisfaction. A good feedback is very important, we welcome for your
kind suggestion or feedback on goods and our service.

FAQ:

1. Could I have prices of your products?

Well welcome. Please feel free to send us an inquiry. You will get our reply in 24 hours

2. Can we print our logo/website/company name on products?

Yes, OEM with autherization is available.

3. What's the lead time for regular order?

7-15 days for order quantity less than 2000pcs; For more quantity, we can negotiate about it

4. Do you inspect the finished products?

Our products100% self-inspection and testing before packing

5. How about payment terms?

30% deposit, the rest payment balance against B/L copy

6.Could you offer Form A or C/O ?

It totally not a problem. We can apply these related documents as our customers' request.
