Self Priming Mini Electric Water Pump , Low Noise Mini Water Pump 12v Dc
Self Priming Mini Electric Water Pump , Low Noise Mini Water Pump 12v Dc
Specifications
Brand Name :
Feiyinsi
Model Number :
SW312-203-2800
Certification :
Rohs,Reach
Place of Origin :
China
MOQ :
negotiation
Price :
Negotiable
Payment Terms :
Western Union, , T/T, L/C,paypal
Supply Ability :
3000pcs per day
Packaging Details :
Export carton, carton's dimension:47*31*25cm
Name :
Mini Electric Water Pump
Size(mm) :
32.8*50*70
Voltage(DC/V) :
12v Dc
Advantage :
Low Noise
Vacuum(Kpa) :
20
Pressure(Kpa) :
500-600
Free Flow rate(L/M) for water :
0.3
Type :
Self Priming
Head/lift (m) :
5-7
life span :
>6000 hours
Description

Self Priming Mini Electric Water Pump , Low Noise Mini Water Pump 12v Dc

Mini Electric Water Pump features

small size

light weight

good durability

maintenance-free

low noise and so on

Mini Electric Water Pump advantage

  1. Extreme chemical resistance
  2. Brush and brush-less direct current motor for selection
  3. Dry running, durable and maintenance free
  4. Self-priming and excellent for pressure

Mini Electric Water Pump application

Cooling systems ·Lab instrumentation

Ink-jet printing systems ·Laser apparatus

Water purification and ultra-filtration

Mini Electric Water Pump parameters

Model SW312-203-2800 Mini Electric Water Pump
Type Self Priming
Voltage(DC/V) 6V,9V,12V,24V
Power(W) 3
Vacuum(Kpa) 20
Pressure(Kpa) 500-600
Free Flow rate(L/M) for water 0.3
Self-priming height(m) 1
Head/lift (m) 5-7
life span >6000hours under continuously working
Weight(G) 160

Self Priming Mini Electric Water Pump , Low Noise Mini Water Pump 12v Dc

Customers how to choose the pump?

1. first determine the voltage, current,water head and flow, diameter size, pump water head is generally the subject of the water does not flow when pumped up to the static head, if a customer requires pumping the water to a certain height and then to maintain a certain water flow, select the desired water head must be higher than the specified pumping height. This specific by the supplier according to the actual conditions. Can refer to lift flow graph.

2. to determine the dimension and form (threaded interface, inlet and outlet orientation, aperture size, etc.)

3. to determine the job requirements (temperature, medium, work time and frequency)

4. to determine the functional requirements (time control, pressure control, flow control, speed, etc

FAQ

1. What is your MOQ?

No MOQ, Welcome to how many quantity.

2. What about the delivery time?

It depends on your order quantity; it usually takes 7-20days upon receipt of full payment.

3. Can I buy different types in one container?

Yes, you can mix different types in one container.

company introduction

Founded in 1999, Yanhua faith is concentrated on mold and plastic injection first.

In 2001, we start our own assemble line to produce pumps.

In 2002, we have our own sales team.

In 2003, we have our over-sales team.

From 2010, we start our own patent, now we have more than 20 patents.

In 2010, yanhua company has passed ISO9001 certification

In 2011years, we have our own trademark”Feinyinsi”.

Today, Yanhua have 12 production lines and 300 skilled workers, our monthly producton capacity is 500,000pcs brushless and brush dc pumps,100,000 piston pumps and 10,000 gear pump and water pump.
