Wide Platform Structure Electric Linear Actuator Adaptive Pushing
Wide Platform Structure Electric Linear Actuator Adaptive Pushing
Specifications
Brand Name :
RobustMotion®
Model Number :
RM-WRPLA-11-50-2-H-ITG
Certification :
CE, RoHs
Place of Origin :
China
MOQ :
2 pieces/sets
Price :
Negotiable
Payment Terms :
Bank transfer
Supply Ability :
TBC
Delivery Time :
5-15work days
Stroke (mm) :
50
Lead (mm) :
2
Max.speed （mm/s） :
100
Max. Pushing Force1（N） :
300
Max. load Capacity Horizontal (kg） :
6
Max. load Capacity Vertical :
0.5
Repeat Positioning Accuracy (mm) :
±0.02
Permissible Load Torque (N.m) :
MR: 9.11, MP: 13.67, MY:13.67
BUS Control :
Modbus RTU
Interface :
Input 2 Points(NPN), Output 3 Points(NPN)
Rated Voltage (V) :
DC24±10%
Rated Current (A) :
2
Weight (kg) :
1.6
Usage Environment :
0~40℃、< 85%RH ( Without condensation)
Protection Class IP :
IP40
Outgoing Line Method :
Horizontal Wiring
Description

Wide Platform Structure Electric Linear Actuator Adaptive Pushing RM-WRPLA-11-50-2-ITG

The Wide platform-type linear actuator (ITG) RM-WRPLA-11-50-2-H-ITG is a top-notch linear actuator with an integrated controller. It stands out with its enormous working platform, surpassing the size of conventional electric push rods. This enables it to bear higher lateral loads and provides a more spacious working area. The platform design allows for effortless installation of various operations and devices while ensuring their stability and dependability. This push rod is ideal for applications involving the movement or transportation of large workpieces, such as automated assembly lines, material transport systems, and workpiece fixation and positioning.

Specifications
Stroke (mm): 50
Lead (mm): 2
Max.speed (mm/s): 100
Max. Pushing Force1(N): 300
Max. Load Capacity Horizontal (kg): 6
Max. Load Capacity Vertical: 0.5
Repeat Positioning Accuracy (mm): ±0.02
Permissible Load Torque (N.m): MR: 9.11, MP: 13.67, MY:13.67
BUS Control: Modbus RTU
Interface: Input 2 Points(NPN), Output 3 Points(NPN)
Rated Voltage (V): DC24±10%
Rated Current (A): 2
Weight (kg): 1.6
Usage Environment: 0~40℃,< 85%RH ( Without Condensation)
Protection Class IP: IP40
