630a Moulded Case Circuit Breaker 660 Volt Four Pole Circuit Breaker
630a Moulded Case Circuit Breaker 660 Volt Four Pole Circuit Breaker
630a Moulded Case Circuit Breaker 660 Volt Four Pole Circuit Breaker
630a Moulded Case Circuit Breaker 660 Volt Four Pole Circuit Breaker
Specifications
Brand Name :
SEFIE
Model Number :
SFM1
Certification :
CB,CE,CCC
Place of Origin :
WenZhou, China
MOQ :
2000-3000
Price :
Negotiable
Supply Ability :
300000pcs per month
Delivery Time :
14 days after receipt of deposit
Packaging Details :
each product one box, accoding the goods size pack carton
Payment Terms :
L/C, T/T
Material :
Plastic
Rated current :
6-63
Rated voltage :
380/660
Port :
Shanghai/Ningbo
Color :
White
Pole :
3,4
Description

SFM1 Series Moulded Case Circuit Breakers MCCB 630a 4 pole circuit breaker

  • SFM1 moulded case circuit breaker with rated insulation voltage800V, applied in the power system of AC50(60)Hz, rated voltage 690V and below, rated current 1250A and below as the transfer not frequently. The circuit breaker has the protection devices of over load, short circuit and under voltage ,it can protect the circuit and power equipment from broken.
  • The mccb can be sorted to C type (basic),L type (standard),M type (high breaking), H type(higher breaking) according to its rated limit short circuit breaking capacity.
  • The mccb has the features small volume, breaking capacity high, electric arcing short ,anti-vibration. It is the ideal product for application in land and ship.
Type SFM1-63 SFM1-100 SFM1-225 SFM1-400 SFM1-630 SFM1-800
Rated Current(A)

6,10,16,20,

25,32,40,

50,63

10,16,20,25,

32,40,50,63,

80,100

100,125,

160,180,

200

225,250,

315,350,

400

400,

500,

630,

630,

700,

800
Pole No 3P,4P
Rated Insulation Volatge(v) 660V
Rated Operation Voltage(v) 380V
Acting over Distance(mm) 0 0/0(≤50) ≤50 ≤50 ≤100 ≤100
Ultimate Short Circuit Breaking Capacity 25,50 25,35,50,85 25,35,50,85 35,50,65 35,50,65,100 65,100
Service Short Circuit Breaking Capacity 18,35 18,22,35,50 18,22,35,50 25,35,42 25,35,42,65 42,65
Operation Performance ON 1500 1000 1000
OFF 8500 7000 4000
