2P 25a RCBO Circuit Breaker Red Copper / 400V Din Rail Circuit Breaker
2P 25a RCBO Circuit Breaker Red Copper / 400V Din Rail Circuit Breaker
2P 25a RCBO Circuit Breaker Red Copper / 400V Din Rail Circuit Breaker
2P 25a RCBO Circuit Breaker Red Copper / 400V Din Rail Circuit Breaker
Specifications
Brand Name :
SEFIE
Certification :
IEC60898,CB,CE,CCC,ROHS
Place of Origin :
Wenzhou,China
Price :
Negotiable
Supply Ability :
500000 pcs per month
Delivery Time :
14 days after receipt of deposit
Model Number :
SFMLE-63
MOQ :
2000-3000
Packaging Details :
one goods install one box,then install one carton
Poles Number :
2P
Rated current :
6 - 63A
Breaking capacity :
6 KA
Material :
Plastic
Mechanical Life :
20000 Times
Rated voltage :
230 / 400V
Description

2P Red Copper RCCB with Overcurrent Protection

1. Provide protection against earth fault/leakage current and function of isolation.

2. High short-circuit ccurrent withstand capacity.

3. Applicable to terminal and pin/fork type busbar connection.

4. Equipped with finger protected connection terminals.

5. Fire resistant plastic parts endures abnormal heating and strong impact.

6. Automatically diconnect the circuit when earth fault/leakage current occurs and exceeds the rated sensitivity

7. Independent of power supply and line voltage, and free from external interference, voltage fluctuation.

Electrical Feature
Rated current(A)
6, 10, 16, 25, 32, 40, 50, 63
Poles
1P+N, 2P, 3P, 3P+N, 4P
Rated voltage(V) Ue
230/400
Rated residual operating current
30mA
Insulation voltage(V) Ui
500
Rated tripping current range(A)
0.5lΔn~1lΔn
Rated frequency(Hz)
50
Standard
IEC61009-1
Breaking capacity(Ka)
6
Break time under l∆n
≤0.1s
pollution degree
Ⅱ
Energy limiting class
3

Mechanical Features
Electrical life
10000
Mechanical life
20000
Contact position indicator
YES
Protection degree
IP20
Working ambient temperature
-35~70℃
Storage temperature
-40~70℃

Installation
Terminal connection type
Cable/U-type busbar/Pin-type busbar
Mounting
On DIN rail IEC60715(35mm) by means of fast clip device
Fastening torque
2.5Nm
Connection capacity
25mm2

2P 25a RCBO Circuit Breaker Red Copper / 400V Din Rail Circuit Breaker
