Chemical Industry Medium Voltage Panel Mv Switchgear Panel For Power Reception
Chemical Industry Medium Voltage Panel Mv Switchgear Panel For Power Reception
Chemical Industry Medium Voltage Panel Mv Switchgear Panel For Power Reception
Chemical Industry Medium Voltage Panel Mv Switchgear Panel For Power Reception
Chemical Industry Medium Voltage Panel Mv Switchgear Panel For Power Reception
Chemical Industry Medium Voltage Panel Mv Switchgear Panel For Power Reception
Specifications
Brand Name :
HENGFENGYOU
Model Number :
XGN,KYN
Certification :
ISO IEC CB COC KEMA SNI SABS CCC
Place of Origin :
China
MOQ :
1
Price :
200-20000/piece
Payment Terms :
LC T/T
Supply Ability :
5000 piece/year
Delivery Time :
30 days
Packaging Details :
wooden case
Type :
metal clad, Box type fixed withdrawable Switchgear
Rated frequency :
AC 50Hz (60Hz)
Rated current(A) :
630, 1250, 1600, 2500, 3510, 4000
Customized :
OEM/ODM order acceptable
Application :
Power transmission or distribution
Product Name :
Electrical kyn28 12 switchgear 11kv
Rated Voltage :
3KV, 7.2KV, 12KV optional
Comply standards :
DL/T404, IEC298,GB3906
Description

High medium voltage electric switch gear control panel

1: XGN2-12 is mainly used for power reception and distribution of 3-6KV-12KV 3 phase AC 50HZ indoor electric system

Specially suitable for working conditions where frequent operations

2: the production is strictly designed according to I standard,also suitable for frequency Shizuku and dirty working conditions.

3: Successfully widely used by Three Georges project, national engineering designing institute, mining company, cement mill, stell mill,sugar factory,wood industry, chemical industry, city planning, and other place with big power motor and high electric consume place.

4: KYN28-12 removable AC metal-clad switchgear (short for panel as below) is a new product. It will be a substitute for old fashioned metal-enclosed switchgear, such as KYN-12, JYN-12, GFC-12, etc. The panel applies to 3.6~12kV 3 phase AC 50Hz network for receiving and distributing power energy and also for control, monitor and protection. It accords with standard of IEC62271-200, IEC60694, GB3906.

Working condition:

relative humidty: daily average value < 95%, monthly average value <90%

No explosion, serious pollution, chemica erosion, excessive vibration

earthquick intensity no over 8 degree

Chemical Industry Medium Voltage Panel Mv Switchgear Panel For Power Reception

Note: Due to continuous product improvement, the dimensions provided in this sample are for reference only. If necessary, our company can design and produce according to user requirements. Please contact the company in time.

Main technical parameters
Main circuit rated voltage(V) .......................... Ac 400 (600)
Rated voltage of auxiliary circuit (V) .......................... Ac 220/380 (400) dc 110/220
Rated frequency (Hz) .......................... 50(60)
Rated insulation voltage(V) .......................... 690(1000)
Rated current(A) The level of bus ≤6000
Rated short-time bus withstand current (kA/1s) .......................... 50,80
Rated peak withstand current of bus (kA/0.1s) .......................... 105,176

Power frequency test voltage (V/1min)

 main circuit 2500
Auxiliary circuit 1760

bus

 Three-phase four-wire system A,B,C,PEN
Three-phase five-wire system A,B,C,PE,N
Protection grade .......................... IP30


4)Main technical parameter

no name unit data
1 rated voltage kv 3, 6,10
2 ratd current A 630,1000,1250,1600,2000,2500,3150
3 rated frequency HZ 50
4 rated short circuit drop out current(effective value) KA 20.25; 31.5; 40
5 rated thermo stable current( peak value) KA 20.25; 31.5; 40
6 rated dynamic current( peak value) KA 40; 80; 100
7 rated power frequency withsand voltage(1min) KV inter-electrode and earth 42; inter -fractures 48
8 ratd thunder impulse withstand voltage KV inter-electrode and earth 75; inter -fractures 85
9 rated thermo stable time KV 4
10 degree of protection IP2X
11 externam dimension(WXDXH) MM 1100x1200x2650( can design according to demand)

Chemical Industry Medium Voltage Panel Mv Switchgear Panel For Power Reception

Chemical Industry Medium Voltage Panel Mv Switchgear Panel For Power Reception
