Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Specifications
Place of Origin :
Hebei, China
Brand Name :
Zhufeng
Model Number :
YTTW
Insulation Material :
Inorganic Mineral
Type :
LOW VOLTAGE
Application :
Construction, Underground, Industrial, Power Station
Conductor Material :
Copper
Jacket :
Copper
Number of Cores :
1core
Specification :
10-400mm²
Transport Package :
Wooden Drum
Certification :
ISO, CCC, CE, RoHS, Ice, En, BS
Rated voltage :
0.6/1KV
Other Service :
Can be customized
Packaging Details :
Packed in wooden case on pallet or according to your requirements for power cable
Port :
Tianjin port, Qingdao port, Shanghai port, Guangzhou port
Supply Ability :
20000 Kilometer/Kilometers per Month
MOQ :
1000 meters
Price :
$0.99/meters 1000-4999 meters
Description
Product Description
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Specification
item
value
Place of Origin
China
Hebei
Brand Name
Zhufeng
Model Number
YTTW
Insulation Material
Inorganic Mineral
Type
LOW VOLTAGE
Application
Construction, Underground, Industrial, Power Station
Conductor Material
Copper
Jacket
Copper
Number of Cores
1core
Specification
10-400mm²
Transport Package
Wooden Drum
Certification
ISO, CCC, CE, RoHS, Ice, En, BS
Rated voltage
0.6/1KV
Other Service
Can be customized

Usage Characteristics

1 .Fire-proof performance is excellent, fire-resistant grade can not only meet the national standard GB/T 19216-21 A 950 C.90 min (BS6387:2013 C 950 C. 3 h requirements), but also can withstand water spraying and mechanical impact in combustion. 2 .Continuous length, whether single core or multi-core cable, can meet the needs of power supply length, the limit length can reach 2000m. 3 .The cross-section of single-core cable is large, and the cross-section of single-core cable can reach 1000 mm2, and that of multi-core cable can reach 240 mm2. 4 .The overload capacity is large, the cable not only has a large carrying capacity, but also has a large overload capacity. According to the wiring requirements, the surface temperature of the cable is usually less than 70 C. If the wiring is not touched or contacted with flammable building materials, the temperature of cable sheath can reach 105 C. and the allowable working temperature of fire-proof cable can reach 250 C when it is cut off. 5 .No electromagnetic interference, fire-proof cables and signals, control cables are laid in the same shaft. When the fire-proof cables are shielded by copper sheath, they will not interfere with the information transmitted by signals and control cables. 6 .The cost of flexible fire-proof cables is lower than that of mineral insulated cables under the same conditions because of its advanced fabrication technology and simple installation.
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
Fire-resistant Mineral Insulated Cable 70mm 95mm 120mm for Underground Applications
