160A Din Mount Fuse Holder NT00 NT0 Series White Color GB13539
160A Din Mount Fuse Holder NT00 NT0 Series White Color GB13539
160A Din Mount Fuse Holder NT00 NT0 Series White Color GB13539
160A Din Mount Fuse Holder NT00 NT0 Series White Color GB13539
160A Din Mount Fuse Holder NT00 NT0 Series White Color GB13539
160A Din Mount Fuse Holder NT00 NT0 Series White Color GB13539
Specifications
Brand Name :
OEM
Model Number :
NT00C, NT00, NT0
Certification :
CE,TUV,CB,RoHS
Place of Origin :
ZHEJIANG,CHINA
MOQ :
500pcs
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
2000 Piece/Pieces per Day
Delivery Time :
15 DAYS AFTER PAYMENT
Packaging Details :
Standard Export Package
Rated Voltage :
500V 690V
Rated Current :
125A, 160A
Type :
Fuse Links
Color :
White
Breaking Capacity :
up to 120KA
Material :
Copper, Porcelain or Brass
Usage :
Low Voltage
Function grade :
gG / gL / aR / aM
Description

Fuse Links Selection Guide:

Usual Service Conditions and Installation Conditions:

  1. Ambient temperature:-5℃~+40℃
  2. Height above sea level not more than 2000m.
  3. Class of pollution: Third class
  4. Sort of installation: III

Rated breaking capacity:

Rated breaking capacity is the maximum short-circuit current allowed for the fuse link to cutout reliably under rated voltage. The instantaneous current loaded to the fuse link is much larger than the normal working current when short-circuit occurs. The fuse link is supported to cutout the line in an undamage condition i.e. without bursting. The rated breaking capacity of TIRH fuses is up to 120KA and the excellent current limiting characteristics reliably protect the equipment form damages by electric power.

Low Voltage H.R.C Fuse NT00C,NT00,NT0 series

Applications:
This series of fuse links is mainly used in AC 50Hz, rated voltage up to 1140V, rated current up to 1250A and for pro- tecting electric equipment from overload and short-circuit. It can reliably break the min fusion current to any current wit- hin 120KA.

It is also available for the protection of semiconductor parts and equipments against short-circuit(type aR)and prote- ction of motors(type aM).

This series of fuse links conforms to GB13539 and EC 60269 standards.

Design Features:
It adopts the material with high quality. The arc-extinguishi- ng medium is quartz sand and fuse tube is high strength ceramic. The advanced manufacturing craft work ensures the performance of small power waste stable characteristic for the product. The outline structure and insta lation dime- nsion joints the advanced similar products from domestic and abroad.

Technical Specification:

Code No. Product model Domestic and overseas similar products Rates Voltage(V) Rated current(A) Overall dimension(mm)
gG aR A C D E H
18008 RO30A NH00C 　 500/690 4-125 78 49 21 15 48
18009 RT16-000 NT00C NH00C RS30C 500/690 4-125 78 49 21 15 52
18010 RT16-00 NT00 NH00 RT20-00 3NA RS31 500/690 4-160 78 49 29 15 56
18011 RT16-0 NT0 NH0 　 500/690 4-160 125 68 29 15 56

160A Din Mount Fuse Holder NT00 NT0 Series White Color GB13539

Factors To Be Considered For Selection of Fuses:

  1. Normal working current
  2. Working voltage
  3. Ambient temperature
  4. Overload current and cutout time
  5. Possible malfunction current
  6. Impulse current, surge current, starting current and transient value of the line
  7. Size and dimensions, connection methods, indicators, etc.

Ambient Temperature:

Ambient Temperature means the air Temperature directly around the fuse, and should not be understood as the room temperature. In many application cases, the fuses are at rather high temperature as they are installed with supporting devices or bases in different structures and they are closed in the distributing or controlling boxes.

Further information:

1. Plastics materials: all raw materials are brand-new and second-hand materials are forbidden. Furthermore some of them are supplied by super branding companies like DSM, Mitsubishi.

2. There is just one level of quality as A in MEIHENG and we are aim to provide the excellent articles to our clients and help them gain more market shares.

3. ODM: we are providing ODM services to the super companies (more than 15) who are top-10 electrical industrial companies in their country. Just show us your ideas and we will present a solution.


FAQ:

A. How's the delivery time?
Depend on your quantity, usually within 20days after receiving deposit

B. Would you accept OEM/ODM service?
Glad to say that there is planning department, technical department and mould tooling center in
our factory. For the OEM & ODM, it is ok for us if your brand, market shares are great.

C. Would you offer free sample?
Samples are freely provided and shipping costs is paid on your end usually.

D What's your guaranty time?
At least 2 years and depend the product

E What's your payment term?
T/T, L/C; other terms is negotiable after further check
