2P Polarity Power Cord Testing Equipment Plug Integrated Tester 4.4 Seconds / Bar
2P Polarity Power Cord Testing Equipment Plug Integrated Tester 4.4 Seconds / Bar
Specifications
Brand Name :
Kinte
Model Number :
CTI-23ANPK-U2
Certification :
Certificate of conformity of quality management system certification
Place of Origin :
Guangdong,China (Mainland)
MOQ :
1 Set
Price :
customized
Payment Terms :
L/C, T/T
Supply Ability :
customized
Delivery Time :
customized
Packaging Details :
customized
Description

2P Polarity Power Cord Testing Equipment Plug Integrated Tester 4.4 Seconds / Bar ​

Model: CTI-23ANPK-U2

Application: Inspect the polarity, insulation, core high voltage, exposed copper and relative length of

power plug wire.

Conform to standard: UL, VDE, SAA, T-MARK, KS, IRAM, CCC , BSI1363 and other national

standards Master: Japan's Mitsubishi PLC control center, 5.7-inch touch screen interface

Grounding resistance: E pole current AC25A can be preset, L, N pole AC3A / 5A wire Sensitivity:

≥ 10PF ± 5% Insulation voltage: DC500V ± 5% Insulation resistance: with or without insulation

Optional: Insulated when the alarm value is 5MΩ Fixed high voltage: AC2.8KV ± 5% Fixed

leakage current: 1.5mA ± 5% Fixed external pressure: AC: 4.2 / 6kv ± 5% Choice of test time: 1s

2s 3s three time value selection. 2P Polarity: 4.4 seconds / bar; 3P Polarity: 6 seconds / Article

test line type: 24 kinds of combination mode Counter: qualified goods, defective goods

automatic counting And display, a suspended count function Power: AC380V / 50Hz, 5A optional

automatic scissors
