Two In One Stator Testing Machine , High Voltage Hipot / Surge Test Equipment
Two In One Stator Testing Machine , High Voltage Hipot / Surge Test Equipment
Two In One Stator Testing Machine , High Voltage Hipot / Surge Test Equipment
Two In One Stator Testing Machine , High Voltage Hipot / Surge Test Equipment
Two In One Stator Testing Machine , High Voltage Hipot / Surge Test Equipment
Two In One Stator Testing Machine , High Voltage Hipot / Surge Test Equipment
Specifications
Brand Name :
AIP
Model Number :
AIP89**
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Supply Ability :
100 sets per month
Delivery Time :
20 days after receiving advance payment
Packaging Details :
Wooden package
Product name :
Two In One Stator Testing Machine
Test :
Hipot and surge
High voltage :
3KV/5KV
MES connection :
Yes
Remote control :
Yes
Warranty :
12 months
Description

Two In One Stator Testing Machine, Hipot And Surge Stator Tester

1. Test object:

Stator or product with windings

2. Test station:

Desktype with test clamps

Two In One Stator Testing Machine , High Voltage Hipot / Surge Test Equipment

3. Technical specification

Test item Surge and Hipot,
Test object Stator, winding
Surge
output voltage setting range/precision 500～3000V ±(3%×display value+8V)
waveform comparison

area, area difference, corona, phase

three waveforms will be displayed on the testing interface
Hipot
output voltage setting range/precision AC 200～3000V ±(3%×setting value+10V)
breakdown current measuring range/precision 0.10～25.00mA ±(3%×display value+5 words)
breakdown current presetting alarm range Max: 0.10～25.00mA; Min: 0.00～5.00mA
test time range/resolution 1～300s 1s/step

4. ​After-sales service

  • Function module is designed as separate board card, and the failure board card can be positioned quickly.
  • Self-diagnose function: the tester will diagnose its function module board card automatically every time it has been switched on, and position the failure module accurately.
  • Support remote control failure inspection
