Specifications
Brand Name :
DREAM WHEEL
Model Number :
EBS222
Certification :
EN15194
Place of Origin :
CHINA
MOQ :
5 units
Price :
USD
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
1800PCS per month
Delivery Time :
25 days
Packaging Details :
Carton and protecting cover; one piece per carton
Speed :
25km/h
Color :
Grey, Black
Motor power :
36V 250W BAFANG rear motor
Wheel size :
26”
Standard :
Europe standard
Package :
Carton and protecting cover
Description

Citizen E Bike Motor 250W Lady Eco Electric Bike Europe Electricbike Disc Brake

Quick Details

1. Motor power: 36V 250W BAFANG rear motor

2. Frame material: Aluminum alloy 6061

3. Lithium battery: 36V 10.4Ah Samsung cells

4. Certification: EN15194

5. Wheel size: 26”

6. Brake system: Disc brake for front; Shimano V brake for rear

7. Derailleur system: Shimano tourney TX55

8. Pedals assisted system: Yes

Product Descriptions

This electric city bike is our classic model, we have sold for 3 years in Italy, Sweden and Canada. At present, main market is Europe and America. This electric city bike adopt Shimano out 6 derailleur , and 36V 250W BAFANG classic rear mounted motor, can give driver more help to meet various road condition.

Components

1. BAFANG rear Gear motor, China famous electric bike motor supplier. This rear-drive motor, which is compatible with the disc brake, has a rated power of 250-500W, a reduction ratio of 1: 5 and a maximum torque of 48 N.m, providing ideal power for vehicles.

2. Shimano TX rear derailleur

more positive gear-changing due to less flex in the parallelogram

better gear-changing with good cable leverage

better obstruction clearance

less danger of catching spokes.

slight weight savings.

3. ZOOM fork, city trekking series, made with Spring pressure system, adjustable preload, mechanical easy lock-out.

4. ZOOM disc brake, from TAIWANG high quality brake system supplier

5. Velo seat, high end seat supplier from TAIWAN, in any case, the wider and more comfortable seat can provide more experiences for riders.

6. SPANNINGA high quality LED headlamp, from Netherlands

Specifications

Model number

EBS222

Motor

BAFANG, 36V 250W rear GEAR motor

Battery

36V 10.4Ah lithium, SAMSUNG cells

Charge time

4-8h

Charger

110-240V, 36V 2A, plug can be customized

Controller

36V 14A

Speed

25Km/h

Driving distance

55-60km by PAS

Weight

26Kgs

Packing dimension

1700x250x780mm

Panel/speedometer

LCD display

Wheel

26”

Tire

26”x1.75, KENDA on road tire

Chain

1/2*1/8*110L, KMC rust-proof

Frame

Aluminum alloy 6061

Fork

26”, travel 100MM, 28.6*25.4*202L*100MM

Shift lever

Shimano 6 speed

Rear derailleur

Shimano RD-TX55

Front brake

ZOOM Disc Brake

Rear brake

Shimano V Brake

Brake levers

Aluminum

Rims

Aluminum alloy,26”*1.75*36H*13G

Spokes

Front:13GX245/247; Rear:13GX243/242;

Pedals

Wellgo, with ball

Chainwheel

1/2*3/32*44T, aluminum

Cranks

Aluminum, 170L

Freewheel

14-28T

Handlebar

ZOOM Aluminum, W610x2.0T

Stem

ZOOM Aluminum

Grip

140MM

Seat

Velo, Black&white

Seat tube

Aluminum with suspension, 27.2*300*2.0T

Lamp

LED for front, SPANNINGA

Wheel base

1170mm

Min ground clearance

110mm

Saddle ground clearance

Max:990mm; Min:790mm

Handlebar ground clearance

1150mm

Licence requirement

NO
