10 Ton Heavy Duty Horizontal Beam Lifting Clamp Jaw Opening 0-125mm
10 Ton Heavy Duty Horizontal Beam Lifting Clamp Jaw Opening 0-125mm
10 Ton Heavy Duty Horizontal Beam Lifting Clamp Jaw Opening 0-125mm
10 Ton Heavy Duty Horizontal Beam Lifting Clamp Jaw Opening 0-125mm
Specifications
Brand Name :
SEAGULL
Model Number :
DHQ
Certification :
ISO
Place of Origin :
China,Jiangsu
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
2500 piece per month
Delivery Time :
30 days
Packaging Details :
High quality double wall carton and steel pallets outside.
Material :
steel
Condition :
New
Usage :
lifting steel plate
Color :
Optional
Warranty :
1 year
Description

10 Ton Heavy Duty Horizontal Beam Lifting Clamp Red Color

Product Description

Capacity from 0.75T to 5T.

*Forged head and forged gear set ensure the durability and safety.

* Gripper is HRC 52-57 for longlife use.

*More thickness of the steel plates to ensure the good safety.

*One year guarantee.

10 Ton Heavy Duty Horizontal Beam Lifting Clamp Jaw Opening 0-125mm

Technical Data Sheet

Model DHQ-0.8 DHQ-1 DHQ-1.6 DHQ-2 DHQ-3 DHQ-4 DHQ-5 DHQ-6 DHQ-6(B) DHQ-8 DHQ-10
Rated Capacity(T) 0.8 1.0 1.6 2.0 3.0 4.0 5.0 6.0 6.0 8.0 10.0
Test Load 1.6 2.0 3.2 4.0 6.0 8.0 10.0 12.0 12.0 16.0 20.0
Jaw Opening(mm) 0-25 0-30 0-30 0-40 0-45 0-50 0-55 0-65 0-130 0-100 0-125
Net Weight 2.5 3.5 4.0 5.0 6.0 6.5 7.5 10.5 22.0 22.0 33.0

Product instructions

  • Not to do heavy lifting, class hanging, hanging, hanging off the crane and cross hanging crane
  • Never enter the hanging material or flip the area
  • Do not knock or crash on hanging objects and spreaders
  • Do not move or stop abruptly
