30 Ton Manual Chain Block Light - Weight Steel Body With Durable Powder Coat
30 Ton Manual Chain Block Light - Weight Steel Body With Durable Powder Coat
Specifications
Brand Name :
SEAGULL
Model Number :
HSZ-E
Certification :
GS/CE
Place of Origin :
CHINA
MOQ :
100pcs
Price :
Negotiation
Supply Ability :
15,000pcs per month
Delivery Time :
30 working days after received your payment
Packaging Details :
Packed in carton firstly,and then reinforced with steel case for outer packing
Payment Terms :
L/C, D/A, D/P, T/T
Product Name :
Manual Chain Block
Application :
Warehouse, Building, Wharf, Ect.
Capacity :
0.5t - 30t
Surface :
Paintng, Chorme
Standard :
GS/CE
Type :
Manual
Description

0.5T - 30T MANUAL CHAIN BLOCK

PRODUCT SUMMARY
SEAGULL manual chain hoist features steel-casting housing, Grade 80 chain and a compact design that's perfect for tight spaces. Black finish lift chain is rust resistant and durable, while zinc-plated pull chain resists rust. All-steel construction for durability and wear resistance.

DESCRIPTION

* Capacity from 0.5T to 30T.

* gear assembly to be efficient for operation.

* light-weight steel body with durable powder coat.

* Drop forged hooks and hook holders to ensure superior quality and safety.

* Asbests-free brake discs.

* Bearing mechanism to increase mechanical efficiency.

* The static test is 4times of capacity, and running test is 1.5times of capacity one by one.

* More thickness of sheet cover,gear cover and side plates for good quality.

* G-80 load chain for sprocket made of alloy steel with precision machining has been got well heat-treatment.

* CE AND GS CERTIFIED.

* One year guarantee.

KEY SPECS

Model Rated Load
(Ton)		 Standard
Lift (m)		 Test Load
(Ton)		 Efforts Required
at Capacity (N)		 Diameter of
Load Chain (mm)		 No. of Load
Chains		 Major Dimensions(approx) (mm) Net Weight
(kg)		 Extra Weight Per Meter
of extra Lift (kg)
A B C D
HSZ-0.5E 0.5 2.5 0.75 262 6 1 142 126 280 28 9.5 1.7
HSZ-1E 1 2.5 1.5 314 6 1 142 126 300 32 10.5 1.7
HSZ-1.5E 1.5 2.5 2.25 343 8 1 178 142 360 38 17.5 2.4
HSZ-2E 2 2.5 3 318 6 2 142 126 380 40 14.5 2.5
HSZ-3E 3 3 4.5 347 8 2 178 142 470 44 23 3.7
HSZ-5E 5 3 7.5 382 10 2 210 165 600 50 35 5.3
HSZ-10E 10 3 12.5 390 10 4 358 165 730 64 68 9.7
HSZ-20E 20 3 25 390 10 8 580 195 1000 82 155 19.4
HSZ-30E 30 3 37.5 394 10 10 688 394 1050 82 233 23.9
