50Hz 1140V Fuse Protector / Fuse / Low Voltage Fuse Links / NH Series / NH1
50Hz 1140V Fuse Protector / Fuse / Low Voltage Fuse Links / NH Series / NH1
50Hz 1140V Fuse Protector / Fuse / Low Voltage Fuse Links / NH Series / NH1
50Hz 1140V Fuse Protector / Fuse / Low Voltage Fuse Links / NH Series / NH1
50Hz 1140V Fuse Protector / Fuse / Low Voltage Fuse Links / NH Series / NH1
50Hz 1140V Fuse Protector / Fuse / Low Voltage Fuse Links / NH Series / NH1
50Hz 1140V Fuse Protector / Fuse / Low Voltage Fuse Links / NH Series / NH1
50Hz 1140V Fuse Protector / Fuse / Low Voltage Fuse Links / NH Series / NH1
Specifications
Brand Name :
YOMIN
Model Number :
NH series
Certification :
CE / RoHS
Place of Origin :
Zhejiang , China ( Mainland )
MOQ :
10 Piece
Price :
Negotiation
Payment Terms :
L/C , T/T , Western Union , Paypal
Supply Ability :
1000 Pieces Per Week
Delivery Time :
5 - 20 working days after received your payment
Packaging Details :
Export carton , 1 Piece / Carton
Usage: :
Low Voltage
Breaking Capacity: :
High
Safety Standards: :
IEC
Parts-making: :
Self-making
ODM,OEM :
welcome
Metal material :
Brass and iron
Description

50Hz 1140V Fuse Protector / Fuse / Low Voltage Fuse Links / NH series / NH1

Application:
This series fuse is suitable for AC 50Hz,rated voltage to 1140V,rated current to 1250A.lt is mainly used in the electric installation for protecting ircuit from overload and short circuit(gG/GL);it also may derive for protecting the semiconductor device and others complete set installment from hort-circuit(aR)as well as the electric motor from short-circuit(aM). he rated breaking capability for this series fuse is to 120KA.This series fuse conforms to national standard GB13539 and International electrical committee standard IEC60269.

Specificaton:

No. Fuse model Rated voltage Rated current Overall dimension Weight
This company Similar products at home and abroad
Common Fast Common Fast Size Drawing
number		 A B C D G E F H
0101 RT16-00 NGTC-00 NT00 NH00 RS31 3NE80 500/660 4~160 00 1.1 78 52 15 29 56 175
0102 RT16-0 NGTC-0 NT0 NH0 RS31B 3NE41 500/1140 4~160 0 1.1 125 68 15 29 56 252
0103 RT16-1 NGTC-1 NT1 RT20-1 3NA1 RS32 3NE12 500/660 63~250 1 1.2 135 72 20 48 61 455
0104 RT16-2 NGTC-2 NT2 RT20-2 3NA1 RS33 3NE13 500/660 80~400 2 1.2 150 72 26 58.5 71 580
0105 RT16-3 NGTC-3 NT3 RT20-3 RO34 RS34 3NE14 500/660 160~630 3 1.2 150 72 31 67 84 880
0106 RT17 NT4 RO39 Rs39 500/660 500~1250 4 1.3 200 90 50 97 8 150 16.5 113 2470
