EM115 CT 1 Module Self Power LCD Display Digital Electric Meter Reverse
EM115 CT 1 Module Self Power LCD Display Digital Electric Meter Reverse
Specifications
Place of Origin :
China
Brand Name :
Fineco
Model Number :
EM115 CT
Packaging Details :
Standard export packing for Self power supply LCD display digital electric meter reverse
Supply Ability :
5000 Unit/Units per Month
MOQ :
200 units
Price :
$17.00/units 200-999 units
Display Type :
Digital Only
Phase :
Single Phase
Measuring Energy Range :
99999.9
Accuracy Class :
Class1
Output Voltage :
120/230V
Operating Temperature :
-25 to 75
Dimensions :
18*104.5*60
Product name :
Self power supply LCD display digital electric meter reverse
Module :
1 module
Communication :
Modbus RTU/M-bus
Certificate :
CE
OEM :
yes
Color :
White
Port :
Shanghai
Description
Product Description
Self power supply LCD display digital electric meter reverse

EM115 CT 1 Module Self Power LCD Display Digital Electric Meter Reverse

Main Functions and features:

  • Single phase metering
  • CT 60A 330mv AC input
  • Standard DIN rail Format (DIN43880)
  • CI.1(kWh) according to EN62053-21 .
  • CI.2(kvarh) according to EN62053-23
  • Energy consumption LED
  • LCD display , total kWh energy and kvarh readout: 5+1 DGT
  • Green backlight display
  • Instantaneous variables: V, A, W, var , PF, Hz
  • 2 pulse output
  • Smart communication port,
  • RS485&M-bus can selected
  • Self power supply
  • Memory back-up (EEprom)
  • 18mm wideth 1 modual

Meter specification:

Voltage(v)

120/ 230

Operational voltage

(70%-130%)Un

CT

60A/0.33V

Power consumption of current circuits(VA)

< 0.01

Power consumption of voltage circuits(W)

< 1.3W

General data

Frequency (Hz)

50/60

Accuracy

Current

±0.5%

Voltage

±0.5%

Frequency

±0.1Hz

Active power

±1%

Reactive power

±2%

LED

Red led,1000imp/kWh

Output specification

Pulse duration

≥100ms < 120msec (ON),

≥120ms (OFF)

Insulation

4000 VRMS output to

measuring inputs

Memory back-up

EEprom

Connections

Cable cross-section area

Screw-type

Min 2.5mm2 Max 10mm2

Other terminals: 1.5mm2

DIN House(W×H×D)

17.5×90×67.5
