T2 Class C Lightning Arrester 1P Surge Protective Device Remote Signal Or Intelligent Monitoring Module
T2 Class C Lightning Arrester 1P Surge Protective Device Remote Signal Or Intelligent Monitoring Module
T2 Class C Lightning Arrester 1P Surge Protective Device Remote Signal Or Intelligent Monitoring Module
T2 Class C Lightning Arrester 1P Surge Protective Device Remote Signal Or Intelligent Monitoring Module
T2 Class C Lightning Arrester 1P Surge Protective Device Remote Signal Or Intelligent Monitoring Module
T2 Class C Lightning Arrester 1P Surge Protective Device Remote Signal Or Intelligent Monitoring Module
Specifications
Certification :
TUV/CB/CE/IEC/ROHS
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
D/A, L/C, D/P, T/T
Supply Ability :
10000 pcs per Month
Delivery Time :
4-7weeks
Packaging Details :
72*90*69mm
Warranty :
1 year
Type :
Surge protector
Response Time :
Less than 100 nanosecond
Indicator Lights :
Yes
Degree of protection :
IP20
Range of operating temperatures :
-40ºC~+80ºC
Pole :
1P
Test standards :
EN/IEC61643-11(Type 2 /Class 2/T2/Class C)
Description

T2 Class C Lightning Arrester Energy Good Quality Surge Protective Device 1P

Product Description

Surge protection device to prevent lightning surge voltage in low-voltage electrical system or solar energy system (photovoltaic power supply system). These devices must be installed in parallel on the low-voltage distribution system or DC power supply system to be protected, and provide common and different modes of protection. Its installation location is recommended to be located at the front end of the household side of the distribution system or at both ends of the DC power line (solar panel side and inverter/converter side), and equipped with matching circuit breakers or fuses

Product Features

1.T2, T1+T2 surge protection devices are available for photovoltaic/low-voltage power system.
2. Module design, easy installation, and replaceable.
3. The color of the visible window indicates the running status, green indicates normal, and red indicates abnormal.
4. No leakage, no working current.
5. Remote signal or intelligent monitoring module (optional).

Product Parameters

Test standards EN/IEC61643-11(Type 2 /Class 2/T2/Class C)
Maximum operating voltage(Ac)Uc 150V 280V 320V 385V 420V NPE:255V
Nominal discharge current(8/20us)In 30kA
Maximum discharge current (8/20us)Imax 50kA
Total lighting current(8/20us)L1/N→PE Itoal 200kA
Voltage Protection Level Up ≤0.8kV ≤1.0kV ≤1.2kV ≤1.45kV ≤1.6kV ≤1.5kV
Response time ta <25ns
Degree of protection IP20
Range of operating temperatures -40ºC~+80ºC
Failure indication Green:normal Red:invalid
Approvals,certification TUV/CB/CE/IEC/ROHS
Pole 1P/2P/3P/4P/1P+N/3P+N
Remote signal interface connection capability Available
Protection Class IP20

FAQ:

Q: Can you offer me sample?

A: Yes, we can offer you sample to test and check quality. but you need to pay for the express cost, the delivery is about 3--5 days after received express shipping cost.

Q:What's the payment term?

A:We acceptT/T, L/C, PAYPAL, CASH.

Q:Whether you could make our brand on your products?

A:Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
