Hollow Shaft Three Phase Induction Motor 1400 Rpm Die Cast Aluminum Housing
Hollow Shaft Three Phase Induction Motor 1400 Rpm Die Cast Aluminum Housing
Hollow Shaft Three Phase Induction Motor 1400 Rpm Die Cast Aluminum Housing
Hollow Shaft Three Phase Induction Motor 1400 Rpm Die Cast Aluminum Housing
Hollow Shaft Three Phase Induction Motor 1400 Rpm Die Cast Aluminum Housing
Hollow Shaft Three Phase Induction Motor 1400 Rpm Die Cast Aluminum Housing
Specifications
Brand Name :
ZOZHI
Model Number :
112M2-4
Certification :
ISO
Place of Origin :
China
MOQ :
1pc
Price :
negotiated
Payment Terms :
T/T, L/C
Supply Ability :
10000pcs/month
Delivery Time :
25 working days after received your payment
Packaging Details :
Packed in cartons,veneer case or wooden case.
Product Name :
Hollow Shaft Motor
Voltage :
230/400V
Phase :
Three phase
Output :
5.5kw/7.5hp
Speed :
1400rpm
Shaft :
24mm
Frame :
100
Material :
Die Cast Aluminum
Pole :
4
Insulation :
Class F
Protection :
IP55
Installation :
B3
IEC Standard :
IE1
Application :
cleaning machine / pressure washer machine
Description

Hollow Shaft Three Phase Induction Motor 1400 Rpm Die Cast Aluminum Housing

Hollow Shaft Motor

  • with aluminum housing is Enclosed Fan Cooled (TEFC)
    with IP55 environmental protection,
    and applicable for cleaning machine use.

    These motors are designed and manufactured following ISO and IEC standards.
    By switching to the H.S. series motor, customers can save up to 10 % energy!
  • Frame material: aluminum.
  • Standard color: black
  • Available in 2, 4, 6 pole motor
  • Optimized compact style construction.
  • Standard mounting construction B3, B14 B5, B34 B35
  • All motors are designed to IP55 degree of protection

50Hz Electric Motor - B3 - Hollow Shaft - Three Phase - 4Pole (1400 RPM)

FRAME POWER RPM COSφ EFF.% VOLT AMPERE
KW H.P. P.F. V A
711-4 0.25 0.35 1370 0.73 64 400 0.8
712-4 0.37 0.5 1350 0.74 68 400 1.1
713-4 0.55 0.75 1350 0.75 66 400 1.6
90L1-4 1.5 2 1400 0.82 78 400 3.4
90L2-4 2.2 3 1400 0.79 77 400 5.4
90L3-4 2.6 3.5 1400 0.8 78 400 7.4
100L1-4 2.2 3 1400 0.8 81 400 5.1
100L2-4 3 4 1410 0.8 81 400 6.9
100L3-4 4 5.5 1420 0.8 82 400 9.4
100M1-4 4.4 6 1420 0.82 83 400 10
112M1-4 4 5.5 1420 0.8 83 400 9
112M2-4 5.5 7.5 1430 0.82 84 400 12.1
112M3-4 6.2 8.5 1425 0.82 84 400 13.5
112L-4 7 9.5 1430 0.8 85 400 13.8
132S1-4 5.5 7.5 1430 0.82 84 400 11.7
132S2-4 7.5 10 1430 0.84 84 400 15.4
132M1-4 9.2 12.5 1430 0.9 85 400 17.8
132M2-4 11 15 1430 0.9 87 400 21.3
132M3-4 12.5 17 1430 0.88 84 400 26
160M1-4 15 20 1450 0.86 89 400 29
160M2-4 18.5 25 1450 0.86 90 400 34

Hollow Shaft Three Phase Induction Motor 1400 Rpm Die Cast Aluminum Housing
FRAME FLANGE FRAME NO APPLICABLE PUMP MODEL
AR PUMP HAWK PUMP INTERPUMP
71 90mm 71 X.M. - R.K. - RG
90 61/90mm 90L XM - RK - RG Series44/49/50/51/58/60/63
100 61/90mm 100L XM - RK - RW - XW - RG RC - RR - RS NHD -NHDP -NMT Series44/49/50/51/58/ 60/ 63
112 61/90mm 112M XM - RK - RW - XW - RG RC - RR - RS NHD - NHDP -NMT -NPM
132 61/90mm 132S RK - XW - RG RR
132 61/90mm 132M RK - XW - XWL - SXW - SHP - RG NMT -NPM -PXI - NLTI -XLTI
160 61mm 160M X.W. - XWL - SWL - SHP

Hollow Shaft Three Phase Induction Motor 1400 Rpm Die Cast Aluminum Housing

Hollow Shaft Three Phase Induction Motor 1400 Rpm Die Cast Aluminum Housing

Hollow Shaft Three Phase Induction Motor 1400 Rpm Die Cast Aluminum Housing
