10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine
10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine
Specifications
Brand Name :
ZOZHI
Model Number :
MS132S-4
Certification :
ISO
Place of Origin :
China
MOQ :
10PCS
Price :
negotiated
Payment Terms :
T/T, L/C, Western Union, E-checking
Supply Ability :
10000pcs/month
Delivery Time :
25 working days after received your payment
Packaging Details :
Packed in cartons,veneer case or wooden case.
Output :
5.5KW /7.5HP
Pole :
4
Motor Bearing: :
C&U (SKF for Choice)
Efficiency: :
IE1
Motor Housing: :
Aluminum
Protection class: :
IP54/IP55
Insulation Class: :
F class
Color :
customizable
Product Name :
3 Phase Induction Motor
Description

MS132M-4 10HP Three Phase Aluminum Induction Motor For Fish Feed Making Machine

3 Phase Induction Motor Description

MS series aluminum housing three-phase asynchronous motors, in line with the relevant provisions of the International Electrotechnical Commission IEC, made of high-quality raw materials, latest design, owning good performance, low noise, small vibration, safe and reliable operation, nice appearance, small size, lightweight, simple structure, easy maintenance, etc. It applies in Fish Feed Making Machine.

1.BRAND: ZOZHI

2.MODEL:MS series

3.PRODUCT CATAGORY: electric motor

4.AMBIENT TEMPERATURE: -15 ℃ <θ<40 ℃

5.POWER RANGE: 0.09-5.5kw

6.RATED VOLTAGE: 380V

7.RATED FREQUENCY: 50Hz (or 60Hz)

8.PROTECTION CLASS: IP54(IP55)

9.INSULATION CLASS:B, F,H

10.WORK SYSTEM: S1


3 Phase Induction Motor Advantage

1. Superior finish

2. Externally Ventilated

3. Lightweight construction

4. Top-mounted terminal box

5. IP55 Protection

6. Interchangeable foot mounting and flange mounting

3 Phase Induction Motor Application

10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine

Technical data

Model Power (V) (HZ) Current (A) Power Factor

Eff

(%)

 Speed (r/min)

Tstart/

Tn

Tmax/

Tn

Ist/

In
HP KW
MS561-2 0.12 0.09 380 50 0.3 0.76 60 2750 2.3 2.4 6
MS562-2 0.16 0.12 0.37 0.78 63 2750 2.3 2.4 6
MS631-2 0.25 0.18 0.53 0.75 69 2800 2.2 2.4 4.5
MS632-2 0.33 0.25 0.68 0.78 72 2800 2.2 2.4 4.5
MS711-2 0.5 0.37 0.98 0.8 73 2800 2.2 2.4 4.5
MS712-2 0.75 0.55 1.35 0.82 75 2800 2.2 2.4 4.5
MS801-2 1 0.75 1.75 0.85 76 2800 2.2 2.4 4.5
MS802-2 1.5 1.1 2.55 0.85 77 2800 2.2 2.4 4.5
MS90S-2 2 1.5 3.36 0.87 78 2800 2.2 2.4 4.5
MS90L-2 3 2.2 4.93 0.87 78 2800 2.2 2.4 5
MS100L-2 4 3 6.31 0.87 83 2880 2.3 2.4 7
MS112M-2 5.5 4 8.12 0.88 85 2890 2.3 2.4 7
MS132S1-2 7.5 5.5 11 0.88 86 2900 2.3 2.4 7
MS132S2-2 10 7.5 14.9 0.88 87 2900 2.3 2.4 7
MS160L-2 25 18.5 34.7 0.9 90 2930 2.3 2.4 7
MS561-4 0.08 0.06 0.27 0.68 50 1300 2.2 2.3 5.5
MS562-4 0.12 0.09 0.36 0.7 54 1300 2.2 2.3 5.5
MS631-4 0.16 0.12 0.48 0.63 60 1400 2.2 2.4 4.5
MS632-4 0.25 0.18 0.65 0.66 64 1400 2.2 2.4 4.5
MS711-4 0.33 0.25 0.83 0.68 67 1400 2.2 2.4 4.5
MS712-4 0.5 0.37 1.12 0.72 69 1400 2.2 2.4 4.5
MS801-4 0.75 0.55 1.56 0.73 73 1400 2.2 2.4 4.5
MS802-4 1 0.75 2.01 0.75 75 1400 2.2 2.4 4.5
MS90S-4 1.5 1.1 2.83 0.78 76 1400 2.3 2.4 5
MS90L-4 2 1.5 3.84 0.78 76 1400 2.2 2.4 5
MS100L1-4 3 2.2 4.2 0.75 75 1400 2.2 2.4 5
MS100L2-4 4 3 6.78 0.82 82 1410 2.3 2.4 7
MS112M-4 5.5 4 8.82 0.82 84 1435 2.3 2.4 7
MS132S-4 7.5 5.5 11.8 0.83 85.5 1445 2.3 2.4 7
MS132M-4 10 7.5 15.6 0.84 87 1445 2.3 2.4 7
MS711-6 0.24 0.18 0.74 0.66 56 900 2 2.2 5.5
MS712-6 0.33 0.25 0.95 0.68 59 900 2 2.2 5.5
MS801-6 0.5 0.37 1.3 0.7 62 900 2 2.2 5.5
MS802-6 0.75 0.55 1.79 0.72 65 900 2 2.2 5.5
MS90S-6 1 0.75 2.29 0.72 69 910 2.1 2.2 5.5
MS90L-6 1.5 1.1 3.18 0.73 72 910 2.1 2.2 5.5
MS100L-6 2 1.5 3.89 0.76 76 940 2.1 2.2 5.5
MS112M-6 3 2.2 5.57 0.76 79 940 2.2 2.3 6.5
MS132S-6 4 3 7.4 0.76 81 960 2.2 2.3 6.5
MS132M1-6 5.5 4 9.75 0.76 82 960 2.2 2.3 6.5
MS132M2-6 7.5 5.5 12.9 0.77 84 960 2.2 2.3 6.5

10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine

10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine 10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine 10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine
10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine 10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine 10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine
10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine 10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine 10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine

10HP Three Phase Aluminum Induction Motor MS132M-4 For Fish Feed Making Machine

What is Fish Feed Making Mchine :

The mill is used to reduce the particle size of the greaves after fat extraction. The reduction in the size required at this stage depends on whether the meal is used directly in compound feeds or passed through a further set of size reduction.

Features

1. The unique crushing chamber that could improve the grinding efficiency

2. Special rotor design program and the hammer sieve gap, which can meet different granularity
