Single Phase Hollow Shaft Motor 230V 24mm 1500w Die Cast Aluminum Material
Single Phase Hollow Shaft Motor 230V 24mm 1500w Die Cast Aluminum Material
Single Phase Hollow Shaft Motor 230V 24mm 1500w Die Cast Aluminum Material
Single Phase Hollow Shaft Motor 230V 24mm 1500w Die Cast Aluminum Material
Specifications
Brand Name :
ZOZHI
Model Number :
712-4
Certification :
ISO
Place of Origin :
China
MOQ :
1pc
Price :
negotiated
Payment Terms :
T/T, L/C
Supply Ability :
10000pcs/month
Delivery Time :
25 working days after received your payment
Packaging Details :
Packed in cartons,veneer case or wooden case.
Product Name :
Hollow Shaft Motor
Voltage :
230V
Phase :
single phase
Output :
0.5hp/0.35kw
Speed :
1400rpm
Shaft :
24mm
Frame :
100
Material :
Die Cast Aluminum
Pole :
4
Insulation :
Class F
Protection :
IP55
Installation :
B3 B5 B14 B34 B35
IEC Standard :
IE1
Application :
cleaning machine / pressure washer machine
Description

Single Phase Hollow Shaft Motor 230V 24mm 1500w Die Cast Aluminum Material

Hollow Shaft Motor

Hollow shaft 230V/50HZ Single Phase 0.5hp/0.35kw single-phase electric motor designed as totally enclosed, aluminum housing,self-external fan, squirrel cage type, B3 Foot Mount low voltage induction motor. Low noise and a variety of power options are available. The unique internal structure provided a high braking force and flexible motor brake. Brake has high reliability for emergency stops and frequently start-stop actions. The motor can efficiently prevent mechanical reversal and heavy load with large inertia and visits quickly.

50Hz Electric Motor - B3 - Hollow shaft - Single Phase - 4Pole (1400 RPM)

FRAME POWER RPM COSφ EFF.% CAPACITOR VOLT AMPERE
KW H.P. P.F. U.F. V A
711-4 0.25 0.35 1360 0.91 57 10 230 2.1
712-4 0.37 0.5 1380 0.94 65 16 230 2.6
90L1-4 1.5 2 1400 0.98 70 45 230 9.5
100L1-4 1.85 2.5 1390 0.97 68 55 230 12.2
100L2-4 2.2 3 1350 0.99 74 70 230 13.1
100L3-4 2.6 3.5 1350 0.96 74 80 230 17.5
112M1-4 3 4 1400 0.98 74 80 230 18.1
112M2-4 3.7 5 1410 0.96 76 100 230 22

Single Phase Hollow Shaft Motor 230V 24mm 1500w Die Cast Aluminum Material
FRAME FLANGE FRAME NO APPLICABLE PUMP MODEL
AR PUMP HAWK PUMP INTERPUMP
90 90mm 90L RC
100 90mm 100L RC - RR - RS - XT NHD - NHDP
112 61/90mm 112M XM - RK - RS-RC - RR

Single Phase Hollow Shaft Motor 230V 24mm 1500w Die Cast Aluminum Material

Single Phase Hollow Shaft Motor 230V 24mm 1500w Die Cast Aluminum Material

Matters needing attention in motor maintenance and maintenance

During the long-term use of the motor, the user should pay attention to its maintenance and maintenance to improve the service life and better serve the mechanical equipment. Here are some issues to be noted in daily care:


Routine maintenance includes removing external dust and oil stains, monitoring unusual noises, and regularly changing lubricants. The oil change cycle is generally 1kh for plain bearings and 5kh for rolling bearings.

Pay attention to environmental protection when maintaining and repairing the motor to avoid pollution at the maintenance site. For example, the motor coil must not be removed by fire. For engines that have been used for more than one year, pay attention to check whether the oil seals, shaft seal rings on the outside of the motor end cover, rubber seals on the junction box seat, junction box cover, etc. are cracked, deformed, severely worn, etc. The parts that cannot meet the sealing performance and requirements should be replaced in time.
