Household Electric Motor Water Pump 1HP With Cast Iron Body , 0.75KW Output Power
Household Electric Motor Water Pump 1HP With Cast Iron Body , 0.75KW Output Power
Specifications
Brand Name :
ZOZHI
Model Number :
IDB-50
Certification :
CE/SGS/ISO
Place of Origin :
China
MOQ :
1pc
Price :
negotiated
Payment Terms :
T/T, L/C
Supply Ability :
30000pcs per month
Delivery Time :
25 working days after received your payment
Packaging Details :
Packed in cartons , overall size:285x150x185mm/pc, N.W.: 5.4kgs
Product Name :
Electric Motor Water Pump
Application :
pumping
Output :
1HP / 0.75KW
Flow Max :
50L/Min
Head Max :
55M
Suction Max :
9M
Inlet/Outlet :
1"x1"
Speed :
2850RPM
Description


Household Electric Motor Water Pump 1HP With Cast Iron Body, 0.75KW Output Power​

PRODUCT DESCRIPTION

IDB series pump is a Vortex pump with a compact structure, mini size, stable operating curves. High head.

Electric Motor Water Pump FEATURES

1. high head, small flow rate, high efficiency, suction to 9m.

2. stable operate curve

3.durable use,for 2500hrs maintenance.

4. easy installation.

5. mini size, easy taking.

6. antirust pump body and support.

7. head: 3~65m. (as a curve)

APPLICATIONS

Vortex water pump with peripheral impeller can offer high pressure to comparatively low powers and have remarkably steady operating curves. And suitable for handling clean water not containing abrasive particles and fluids which are not chemically aggressive to the pump components.

They are highly reliable, light, economical, and easy to use. As a result, they are widely used in domestic applications, particularly the automatic distribution of water from surge tanks, watering gardens, and boosting insufficient mains water pressure.



STRUCTURAL CHARACTERISTICS

Main Specification Standard Optional
Transmission medium Clean Water
Pump body Cast Iron
Impeller Brass
Motor housing Aluminum
Stator&Rotor 1. Cold-rolled silicon steel sheet by a high-speed punching machine. 2. 100% high-quality copper wire
Front cover Cast Iron Brass plate embedded to avoid impeller jam
Bearing Chinese Best Quality Bearing NSK, S.K.F., or on request
Mechanical seal Graphene/Ceramic Silicon Carbon
Shaft Carbon Steel Stainless Steel
Insulation Class B Class F
Protection IP44 IP54
Voltage 220-240V Single Phase On Request
Frequency 50HZ 60HZ
thermal protection No Yes
Automatic Pressure Control System No Yes
Cooling Type External Ventilation
Max. Suction lift 9M
Max. Fluid Temperature +60℃
Max. Environment Temperature +40℃
Installation Horizontal
Connect Type Thread
CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC




TECHNICAL DATA

Model Output A R.P.M. Q.Max H.Max S.Head Pipe Dia LxWxH N.W.
HP / KW 1~220V (l/min) (m) (M) (mm) (Kg)
IDB-35 0.5 / 0.37 1.6 2850 35 35 9 1"x1" 285x150x185 5.4
IDB-40 0.75 / 0.55 3.6 2850 45 50 9 1"x1" 335x180x200 9.6
IDB-50 1 / 0.75 4.8 2850 50 55 9 1"x1" 335x180x200 10.2
IDB-60 1.5 / 1.1 6.2 2850 60 70 9 1½ "x1½" 425x200x225 22



Household Electric Motor Water Pump 1HP With Cast Iron Body , 0.75KW Output Power




Electric Motor Water Pump GUARANTEE

Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
Household Electric Motor Water Pump 1HP With Cast Iron Body , 0.75KW Output Power


F.A.Q.:
1. Q: How about the M.O.Q.?
A: Usually, it is 100 PCS for each model.

2. Q: Are you a factory or a trading company?
A: We have made water pumps, motors, alternators, and diesel generators since 2006
3. Q: Can you do O.E.M.?
A: Yes, we can. Any O.E.M.s are welcome!
4. Q: What are your payment terms?
A: 30% deposit by T/T in advance, pay 70% balance against B/L copy.
5. Q: How about the delivery time?
A: Usually, 10-30days. But it depends on your order quantity.
6. Q: How about the warranty?
A: 1 year from shipped on board date.
