Hot Sale 220 V Small Electric Chain Hoist / Electric Winch

Product details:

CD Hoists are specially designed for higher lifts, faster hoisting & cross travel speeds & moveable on curved tracks can be manufactured accord demand.

MOTORS: We offer hoist & crane duty Vz hour rated squirrel cage induction motors, confirming to IS 325 with comparatively higher H.P. and higher starting torque to reduce handling time. It is flange mounted to suit our design and with Class B or F insulation.

ROPE DRUM: The rope drum is machined & grooved accurately, to ensure proper seating of wire rope in a proper layer. The drum is fitted with two heavy duty Ball / Roller bearings for smooth operation & longer life.

ROPE GUIDE: The rope guide is made of special close grain castings & is specially designed and accurately machined to suit the grooves of the rope drum & prevents the rope from overriding & loosening. It also operates the limit switches provided as a safety feature to limit the over hoisting & over lowering of the hook. The guide is designed to ensure proper tensioning of the rope.

GEAR BOX: Totally enclosed oil splash lubricated & dust free gear box is provided for smooth, trouble free & longer life. All gears are helical type and cut from alloy steel / low carbon steel on hobbing machines for achieving higher precision & a special process of gear toughening ensures smooth, silent, trouble free running of drive system. The pinions and gears are supported on anti-friction bearings on both ends.

CONSTRUCTION: brake, motors, gear box & control panel are independent units and accessible easily. The complete hoist can be easily maintained by keeping it in its installed position, thus saving precious labor as well as down time and maintenance time.

Techinical parameters:

Product description

Electric hoist is a special type of light and small lifting equipment. It is installed on a bridge or gantry crane.
It has the characteristics of small size, light weight, simple operation and convenient use.
The lifting weight is generally 0.1 ~ 80 tons It is 3 to 30 meters.

The main components of wire rope electric hoist include: reducer, running mechanism, reel device, hook device, coupling, flexible cable current introducer, limiter, etc.
Wire rope electric hoist is one of the commonly used lifting equipment in factories, mines, ports, warehouses, freight yards, shops, etc.
It is an indispensable machine to improve labor efficiency and improve working conditions.

They can be used on straight, curved, circular overhead rails on the same plane,
and can also be used on electric single-beam, manual single-beam, bridge, suspension, cantilever, gantry cranes with I-beam as the track .
Electric hoist is widely used in factories, warehouses, docks, power stations, logging sites and other occasions.
It is the most ideal lifting equipment for lifting and transporting items.
