Workshop G80 Chain 220V 800kg Electric Hoist Winch
Workshop G80 Chain 220V 800kg Electric Hoist Winch
Specifications
Brand Name :
KN
Model Number :
CD
Certification :
CE,ISO
Place of Origin :
HENAN,CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1000pcs
Delivery Time :
30 work,days
Packaging Details :
Wooden box
Core Components: :
Motor
Product name: :
HHBB remote control 1 ton electric chain hoist
Voltage: :
220V~440V 50Hz/60Hz
Application: :
Workshop
Capacity: :
1t-30t
Lifting height: :
3m-30m
Color: :
Yellow
Chain: :
G80 Chain
Description

800Kg Elevator Hoist/220V Motor/Kcd Electric Wire Rope Winch

Product Application

2 ton 5 ton 10 ton 16 ton 32 ton monorail electric hoist trolley crane


Our factory can produce 1-50 tons of wire rope electric hoist, including CD and MD type,low headroom hoist,HC type large weight and high working level,HB/BHC explosion proof type , European electric hoist and Chain hoist

The CD and MD type wire rope electric hoist is a kind of light and small lifting equipment, which can be installed on single beam crane, bridge crane, gantry crane, arm cranes ,cantilever cranes, etc. It can also be used as a winch.It is widely used in factories,mines,harbors,warehouses,cargo storage areas and shops.CD has one speed,MD has two speed.

General Introduction of electric chain hoist

Electric chain hoist is a light duty crane lifting equipment. The lifting capacity of electric chain hoist can be from 0.5 ton to 50 ton. There are total three types of electric chain hoists for you. Manual trolley electric chain hoist, fixed type electric chain hoist, electric trolley electric chain hoist. Please choose as your working environment and specific requirements.

Electric chain hoist description (as customized)

lift capacity(T) 1 1.5 2 3 5 10 20
Testing loading(T) 1.25Gn 1.25Gn 1.25Gn 1.25Gn 1.25Gn 1.25Gn 1.25Gn
Motor power(kw) 1.5 3.0 3.0 3.0 3.0 3.0*2 3.0*2
Lift speed(m/min) 6.6 8.8 6.6 5.4 2.7 2.7 1.4
Lift chain quantity 1 1 1 1 2 4 8
Chain diameter(mm) 7.1 10.0 10.0 11.2 11.2 11.2 11.2
Net weight(kg) 61 108 115 122 151 300 480
lift 1 more meter increase weight(kg) 1.1 2.3 2.3 2.8 5.6 8.4 22
Min. Distance between hooks H(mm) 650 800 800 845 1030 1400 1470

Pre-sale:

(1) the most suitable equipment configuration guide customers to choose.

(2) We will send our engineer to your country if necessary.

While-Sale:

(1) products manufactured before the strict inspection (single test machine is not less than 7 hours).

(2) the organization in accordance with the contract delivery.

Post-sale:

(1) assign professional customer service service personnel to the scene to guide the installation and debugging.

(2) on-site training personnel.

(3) Any other problem about electric hoist winch, pls contact our after services. We will try our best to help you Online 24 hours.
